Summary of Contents for Logik L19LDIB10
- Page 1 19” / 22” LED Backlit LCD TV Instruction Manual L19LDIB10 L22LDIB10...
-
Page 3: Table Of Contents
Contents Preparation ....................................4 Unpacking the TV ........................................4 Installing / Removing the Base Stand ................................5 Front / Top View and Controls....................................6 Side View and Sockets ......................................7 Installing Batteries in the Remote Control ..............................8 Remote Control Operation Range ..................................8 Remote Control ........................................9 Connections .................................... -
Page 4: Preparation
Preparation Congratulations on the purchase of your new Logik TV. Your new TV has many features and incorporates the latest technology to enhance your viewing experience. We recommend that you spend some time reading this instruction manual in order that you fully understand these features. -
Page 5: Installing / Removing The Base Stand
Installing / Removing the Base Stand The LCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. DO NOT exert pressure on the front of the TV at any time because the screen could crack. -
Page 6: Front / Top View And Controls
Front / Top View and Controls Item Description POWER LED Illuminates when the TV is in standby and goes off when the TV is turned on. Receives IR signals from the remote control. IR (Infrared Receiver) Do not put anything near the sensor, as its function may be affected. VOL + / –... -
Page 7: Side View And Sockets
Side View and Sockets Item Description TV AERIAL Connect to the aerial socket on the wall with the RF coaxial cable. HDMI (High-Definition Multimedia Interface) provides an uncompressed, all digital audio/ HDMI IN video interface between this TV and any HDMI-device, such as a set-top box, blu-ray player, and A/V receiver. -
Page 8: Installing Batteries In The Remote Control
Installing Batteries in the Remote Control Press and lift the back cover up to open the battery compartment of the remote control. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the batteries with the (+) and ( - ) ends indicated in the battery compartment. -
Page 9: Remote Control
Remote Control STANDBY/ON Switch the TV between on and standby mode. 2 FUNCTION Select among the different input sources: DTV, TV, AV1, AV1/2 YUV/HDMI AV2/SCART, YUV/SCART or HDMI. 3 TV/DTV A short-cut to switch the input source between TV and DTV. - Page 10 16 LIST Display a list of channels saved in the TV tuner memory. 17 GUIDE Display the EPG (Electronic Programme Guide). (DTV AV1/2 YUV/HDMI mode) 18 INFO Display channel information. (DTV mode) 19 SIZE Press to set the letters size of teletext on the screen. (TV mode) 20 SUBTITLE Select subtitle languages programmed on a DTV...
-
Page 11: Connections
Connections Making Video and Audio Connections Not all AV devices have the ability to connect to a TV, please refer to the owner’s manual of your AV device for compatibilty and connection procedures. When connecting any external AV device, do not connect the mains cable to the mains socket until all other connections are complete. -
Page 12: Connecting A High-Definition (Hd) Device With Yuv Scart Adaptor
Connecting a High-Definition (HD) Device with YUV SCART Adaptor Side View of TV Use the supplied YUV SCART adaptor and a component cable to connect the TV’s SCART input socket to an external AV device’s component output socket. Use an audio cable to connect the TV’s AUDIO YUV SCART (L/R) input sockets to the external AV device’s adaptor... -
Page 13: Connecting An A/V Device With Composite Cable
Connecting an A/V Device with Composite Cable Side View of TV Use an AV cable to connect the TV’s AUDIO IN / VIDEO IN sockets to an external AV device’s composite audio/video sockets. (Video = yellow, Audio Left = white, and Audio Right = red) Plug the connected devices into the mains socket before plugging your TV into the mains socket. -
Page 14: Initial Setup
Initial Setup Turning the TV On for the First Time Connect the mains cable to the mains socket after you have completed all the connections. The TV enters standby mode and the power LED on the front panel of the TV will illuminate. / I button on the top panel of the In standby mode, press the TV or the... -
Page 15: Selecting The Input Source
Selecting the Input Source Press the FUNCTION button to display the input source list. Press the buttons to select the input source that you want: DTV, TV, AV1, AV2/SCART, YUV/SCART or HDMI. AV2/SCART YUV/SCART Press the OK button to confirm your selection. HDMI Alternative •... -
Page 16: Using The Features
Using the Features Customising the TV Setting (TV, DTV or Radio Mode Only) Auto Tuning Use this to automatically find and store all available channels. This is normally recommended if some channels have been added / removed by the broadcaster or you have moved house. TV MENU button and then use the buttons to select the TV Press the... -
Page 17: Atv Manual Tuning
The DTV Manual Tuning screen will pop up. Press the buttons to DTV Manual Tuning select the UHF channel number you want to tune. Press the OK button to UHF CH commence the search of that channel. Please select channel then Press OK to search TV MENU button to return back to the previous menu. -
Page 18: Channel Edit
Channel Edit Allows you to edit TV programmes in the Channel List. Press the TV MENU button and then use the buttons to select the TV SETTING menu. Press the buttons and then the OK button or the button to select Channel Edit. -
Page 19: Ci (Common Interface) (Dtv Mode)
CI (Common Interface) (DTV Mode) The common interface allows the use of a Common Access Module to enable you to view scrambled (pay to view) services. These services are provided by TopUp TV and others. The Common Access Module and viewing card can be obtained from the service provider. -
Page 20: Customising The Picture Setting
Customising the PICTURE Setting Allows you to set your preferred picture mode. TV MENU button and then use the Press the buttons to select the PICTURE menu. Use the buttons to select the following options and the buttons to adjust the setting. Picture Mode Cycles among picture mode: Standard / Movie / Dynamic / Soft / Personal. -
Page 21: Customising The Sound Setting
Customising the SOUND Setting Allows you to select an audio-enhancement technique. TV MENU button and then use the Press the buttons to select the SOUND menu. Use the buttons to select the following options and the buttons to adjust the setting. Sound Mode Allows selection of an audio-enhancement technique from among the following options: Standard / Music / Theatre / Voice / Personal. -
Page 22: Customising The Time Setting
Customising the TIME Setting Press the TV MENU button and then use the buttons to select the TIME menu. Use the buttons to select the following options and the buttons to adjust the setting. Clock The clock is set automatically when receiving a digital signal. Alternative You may press the TIME button to select the display type directly. -
Page 23: Customising The Setup Setting
Customising the SETUP Setting Press the TV MENU button and then use the buttons to select the SETUP menu. Use the buttons to select the following options and the buttons to adjust the setting. Language Allows you to select your desired on screen menu language. -
Page 24: Customising The Lock Setting
Customising the LOCK Setting To access the LOCK menu, you must ente the password. Enter the default password “0000” for the first time use. To change password, refer to “Change Password” on page 24. Lock System Lock System is designed to prevent accidental retuning of the TV / losing channels and prevent children watching unsuitable programmes. -
Page 25: Block Channel
Block Channel Block Channel is designed to prevent children watching unsuitable programmes. The Lock System must be set to On for this function to operate. If the Lock System is set to On, a valid password must be entered. TV MENU button and then use the buttons to select the LOCK Press the menu. -
Page 26: Teletext (Tv Mode)
Teletext (TV Mode) Teletext is a free service broadcast by some TV stations which gives up-to-the-minute information on news, weather, television programmes, share prices and many other topics. Using the Teletext control buttons you can view pages of information that are listed in the teletext index. -
Page 27: Digital Teletext (Dtv Mode)
Digital Teletext (DTV Mode) Digital teletext can access special digital teletext services and specific services which broadcast digital teletext. The subtitle will temporarily auto off when digital teletext function is turned on. Teletext within Digital Service LIST button to display the Channel List. Press the In DTV mode, press the buttons to select the teletext channel. -
Page 28: Select A Programme
Select a Programme Press the buttons to select the desired channel and the buttons to select the desired programme, and then press the OK button to confirm. Button Functions in a 7 Days Guide Remote Control Button Function buttons to view schedule of the previous / next day, then press the YELLOW button Press the YELLOW again to confirm. -
Page 29: Maintenance
Maintenance Careful and regular cleaning can prolong the life of your TV. Be sure to disconnect the mains cable from the mains socket before you start any cleaning. Use a soft dry cloth to wipe away the dust from the screen and surfaces. If the surfaces are extremely dirty, clean the TV with a cloth which has been dipped in a weak soapy water. - Page 30 The audio function does not work. • Press the VOL + / - button. Picture OK but no sound • Sound muted? Press the button. • Try another channel. The problem may be caused by the broadcaster. No output from one of the speakers •...
-
Page 31: Display Modes
720P: 1280 x 720 16:9, 4:3 1080I: 1920 x 1080 16:9, 4:3 1080P: 1920 x 1080 16:9, 4:3 Specification Model L19LDIB10 L22LDIB10 Panel System 18.5 inch LCD panel 22 inch LCD panel 1366 pixels (horizontal) x 1680 pixels (horizontal) x Display Resolution... -
Page 32: Safety Warnings
Safety Warnings • Read all the instructions carefully before using the unit Safety and keep them for future reference. • Always disconnect the unit from the mains supply before connecting/disconnecting other devices or • Retain the manual. If you pass the unit onto a third moving the unit. - Page 33 Earphones CAUTION • Listening to loud sounds for prolonged periods of time may permanently damage your hearing. RISK OF ELECTRIC SHOCK DO NOT OPEN • Before putting on earphones, turn the volume down The lightning flash with arrowhead symbol, then put the earphones on and slowly increase the within an equilateral triangle, is intended to volume until you reach a comfortable listening level.
- Page 36 If you require a replacement for any of the items listed below, please quote their corresponding part numbers: Replacement Part Part Number 509-818125W001 (For Model L19LDIB10) TV Base Stand 509-812125W001(For Model L22LDIB10) Remote control (black) 043-A55652W090 YUV SCART adaptor 138-RGB040W001...
