Logik L26DIGB10 Quick Start Manual

26" HD Ready Digital LCD TV

Quick Start Guide

L26DIGB10
Congratulations
on the purchase of your new Logik LCD TV.
Your new TV incorporates the latest technology to enhance your viewing experience.
We would suggest that you allow about 20 mins for initial setup.
Please follow this guide for a successful rst time installation.
1 1
Unpacking
Remove all packaging from the TV. Retain the packaging. If you dispose of it please
do so according to any local regulations.
TV with TV Base
Instruction Manual Quick Start Guide
2 2
Installing the Base Stand
1. Lay the TV down on a at surface with the back side facing up. Please make sure to
place a soft cushioned material (such as a pillow or thick piece of foam) beneath the
screen.
2. Slide in the base stand until the screw holes are aligned. Secure the base stand with
the 4 screws.
3 3
Operating Your Remote Control
1. Press and lift the back cover to
open the battery compartment
of the remote control.
2. Insert two AAA size batteries.
Close the battery compartment
cover.
Install the batteries correctly by following the polarity (+ and -)
indications in the battery compartment.
Remote Control /
AAA Batteries x 2
4 4
Connecting the Aerial
STANDBY MUTE
AUDIO
1 2 3
RECALL
4 5 6
7 8 9 0
TV MENU SOURCE
OK
CH. LIST SOUND EXIT
+ +
VOL PICTURE CH
_ _
SLEEP ASPECT
FREEZE TV/RADIO TEXT
EPG FAV INFO
REVEAL HOLD LIST INDEX
SUBPAGE SIZE MIX SUBTITLE
Digital Switchover
Addendum
Connect one end of the RF coaxial cable to the aerial socket on the wall and the other
end of the cable to the RF (75 ) socket at the bottom of your TV.
Do not connect the TV to the mains supply until you have completed all
the connections.
Screw
Screws x 4
(P.N.209030427B1)
Slide in
1
2
OR
RF coaxial cable
(not included)
Y Pb Pr COMMON INTERFACE
HDMI 1
AUDIO
AC-INPUT CARD FACE FRONT SCART
VGA INPUT VGA INPUT
ANT
100-240V~ 50/60Hz HDMI 2
L R SPDIF
5 5
Connecting to the Mains Socket
STANDBY
OFF ON
To the mains socket
1. Connect the mains cable to the mains socket after you have completed all the
connections.
2. Switch on the POWER ON/OFF switch at the back of the TV. At this stage stage,
the TV switches to standby mode. The power LED on the front panel of the TV
will illuminate.
3. The button on the side panel of the TV or on the remote control to turn the TV
on.
6 6
Turning the TV on for the first time
The first time you turn the TV on, it will go straight into INSTALLATION GUIDE.
1. The default on-screen menu language is set
as English.
2. Press the button and then press the OK
button or the button to select Auto
Tuning.
3. A pop-up screen will be displayed, press the
OK button on the remote control to start
the Auto Tuning.
Well done,
your new TV is now ready to use.
You will nd that there are many exciting features available. To get to know all these
features, please take some time to read the instruction manual provided with your TV.
INSTALLATION GUIDE
Language English
Auto Tuning
INSTALLATION GUIDE
Language English
Auto Tuning
INSTALLATION GUIDE
Language English
Auto Tuning
Please ensure aerial is plugged in!!
Then press OK button.
(P.N.: 4033C261204-V2)
