How to use your LCD TV
LCXW19LN1
-Before Attempting to connect, operate or adjust this product, please save and read the User Guide completely.
-The style, parts, and accessories of the product shown in this guide may be different due to various models.
-The design and specifications are subject to change without notice.
82-233-00043
Advertisement
Table of Contents
Related Manuals for Logik LCXW19LN1
Summary of Contents for Logik LCXW19LN1
- Page 1 How to use your LCD TV LCXW19LN1 -Before Attempting to connect, operate or adjust this product, please save and read the User Guide completely. -The style, parts, and accessories of the product shown in this guide may be different due to various models.
-
Page 2: Table Of Contents
Contents Contents ........................... Page 2 FCC and safety information ................... Page 3 Important safety instruction ................... Page 4 Precautions ........................Page 5 Getting started ......................... Page 6 -Adjusting the view angle of LCD TV ....................Page 6 -Installing the LCD TV on the wall ......................Page 6 -Top panel ............................. -
Page 3: Fcc And Safety Information
FCC and Safety information CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 4: Important Safety Instruction
Important safety instructions l Damage Never use your TV if it is damaged in any way. Always place your TV on a flat level surface avoiding anywhere which may be subject to strong vibration. l Weather It is advisable to unplug the aerial during an electrical storm. l Temperature Avoid extremes of temperature, either hot or cold, place your TV well away from heat sources such as radiators or gas/electric fires. -
Page 5: Precautions
Precautions Please read these precautions before operating the unit Power cord protection To avoid any malfunctions of the unit, and to protect against electric shock, fire or personal injury, please observe the following. Hold the plug firmly when connecting or disconnecting the AC power cord. Keep the AC power cord away from heating appliances. -
Page 6: Getting Started
Thank you for you purchasing this LCD TV. Before you start using this device, please read this User Guide to help you operate this LCD TV. Adjusting the view angle of LCD TV 5˚ 10˚ 1. The vertical angle could be adjusted to 5˚ forward and 10˚ backward. 2. -
Page 7: Top Panel
Top Panel MENU -VOLUME+ -CHANNEL+ SOURCE POWER Front Panel 1. MENU button 5. POWER button Press to display the main menu. Press to turn on/off the LCD TV. 2. VOLUME +/- button 6. Speaker 7. LCD screen Press to adjust the volume level. 3. -
Page 8: Rare Panel
Rear Panel DC IN PC IN SCART IN/OUT SCART ANTENNA IN 17. EARPHONE jack 10. TV Stand 11. Stand cover Output sound signal to earphone, when the 12. DC IN connector earphone is plugged into this LCD TV, the 13. PC INPUT jack build-in speaker will close automatically . -
Page 9: Connections
Connecting to an aerial (antenna) • Connects the 75-ohm coaxial cable to an Aerial or CATV. Aerial/Cable (not supplied) DC IN PC IN SCART IN/OUT SCART ANTENNA IN Connecting to Set Top Box/DVD Recorder/ Satellite Receiver (not supplied) SCART OUT SCART OUT Example (not supplied) -
Page 10: Connecting To External Audio/Video Devices
Connecting to external audio/video devices • Use the Audio/Video/S-video/Scart cables to connect with external audio/video signal sources. DC IN PC IN SCART IN/OUT SCART ANTENNA IN Earphone (not supplied) SCART (not supplied) Audio cable (not supplied) White White Example: Game/DVD Player/ DVD Recorder/Camcorder/VCR Video cable Yellow... -
Page 11: Connect To Personal Computer
Connecting to personal computer • This device also can connect to a computer as computer monitor, you can output audio and video signals from your computer to this LCD TV. • Connect to your computer via audio and video(D-sub connector) cables. •... -
Page 12: Remote Control
Remote control functions Source Button: Select different input sources Power Button: (TV/AV/SVIDEO/PC/SCART/SCART 2) Power on/off 0-9 Number Buttons: Info Button: Direct access the channel Display source (TV/AV/SVIDEO/PC/ by press 0-9 buttons SCART/SCART 2) information. Recall Button: Return to the last viewed channel MTS Button: Mono/Stereo/Dual I/Dual II selection... -
Page 13: Insert Batteries To Remote Control
Insert batteries to remote control 1. Remove the battery cover of remote control. 2. Insert 2 AAA batteries in the correct position 3. Replace the battery cover. NOTE: • Alkaline batteries are recommended. • Remove batteries when the remote control is not using for a long time. •... -
Page 14: Initial Settings
Turning on the power Setting SOUND system 1. Press the Menu button. 1. Plugs the supplied AC power cord to the 2. Press ◄►buttons to select power outlet. CHANNEL. 2. Press the POWER button on the top of LCD and press ▼button to select SOUND SYS. 3. -
Page 15: Basic Operation
Changing to different TV Channel skip 1. Press the Menu button. channels 2. Press◄►buttons to select CHANNEL, • Press 0-9 NUMBER buttons on the remote and press▼button to go to the CHANNEL control to input channel’s number, the channel item. will change after few seconds. -
Page 16: Program Settings
Program settings Teletext operation Before you customize your program settings, • Teletext is a variety of information services make sure you have already followed the which provided by television broadcast “Setting TV channels” procedures (refer to page companies. The content of teletext is only 14). -
Page 17: Osd Operation
Picture Menu (TV/AV Mode) 1. Press Menu button to enter the main menu. 2. Press ◄(Left) ►(Right) to select PICTURE. 3. Press ▲(Up) ▼(Down) button select the option, PICTURE and then press ◄(Left) ►(Right) to adjust the CONTRAST parameter. BRIGHTNESS 4. -
Page 18: Sound Menu (Tv/Av/Pc Mode)
Sound Menu (TV/AV/PC Mode) 1. Press Menu button to enter the main menu. 2. Press ◄(Left) ►(Right) to select SOUND. 3. Press ▲(Up) ▼(Down) button select the option, SOUND and then press ◄(Left) ►(Right) to adjust the BASS parameter. 4. Press OK or Menu button to leave parameter TREBLE setting, press OK or Menu twice to leave the BALANCE... -
Page 19: Channel Menu (Tv Mode)
Channel Menu (TV Mode) 1. Press Menu button to enter the main menu. 2. Press ◄(Left) ►(Right) to select CHANNEL. 3. Press ▲(Up) ▼(Down) button select the option, CHANNEL and then press ◄(Left) ►(Right) to adjust the ► AUTO SCAN parameter. -
Page 20: Setup Menu (Tv/Av/Pc Mode)
SETUP(TV/AV/PC Mode) 1. Press Menu button to enter the main menu. 2. Press ◄(Left) ►(Right) to select SETUP. 3. Press ▲(Up) ▼(Down) button select the option, SETUP and then press ◄(Left) ►(Right) to adjust the ◄ ► AUTO OFF parameter. ◄... -
Page 21: Osd Menu (Tv/Av/Pc Mode)
OSD Menu (TV/AV/PC Mode) 1. Press Menu button to enter the main menu. 2. Press ◄(Left) ►(Right) to select OSD. 3. Press ▲(Up) ▼(Down) button select the option, and then press ◄(Left) ►(Right) to adjust the ◄ ► LANGUAGE ENGLISH parameter. -
Page 22: Pc Menu (Pc Mode)
PC Menu (PC Mode) 1. Press Menu button to enter the main menu. 2. Press ◄(Left) ►(Right) to select 3. Press ▲(Up) ▼(Down) button select the option, and then press ◄(Left) ►(Right) to adjust the CONTRAST parameter. 4 Press OK or Menu button to leave parameter BRIGHTNESS setting, press OK or Menu twice to leave the H-POSITION... -
Page 23: Troubleshooting
Troubleshooting SYMPTOM (COMMON) REMEDY No picture on LCD TV • Make sure the power is already connected to the power outlet • Make sure the you are on the correct input signal mode, if not, please switch it, for example, switch the TV/AV mode. •... -
Page 24: Specification
Specifi cations Panel User interface Screen 19” wide, WXGA Graphic user interface Support Resolution 1440x900 OSD language Multi-language support Brightness 350 cd/m (typ.) Screen saver Support Response time 5 msec (typ.) Auto power off Support Contract ratio 700 (typ.) Plug & play Support Viewing angles 170/160 (typ.)
