Logik L22DIGB11 Quick Start Manual

22" HD Ready 1080p Digital LCD TV
Quick Start Guide
L22DIGB11
Thank you
for purchasing your new Logik TV.
Your new TV incorporates the latest technology to enhance your
viewing experience. We would suggest that you allow about 20
mins for initial setup.
Please follow this guide for a successful rst time installation.
GB
1 1
Unpacking
Remove all packaging from the TV. Retain the packaging. If you
dispose of it please do so according to any local regulations.
LCD TV Instruction Manual
Base Stand Quick Start Guide
Remote Control / Digital Switchover
AAA Batteries x 2 Addendum
Screw A
2 2
Operating Your Remote Control
1. Press and lift the back
cover up to open the
battery compartment
of the remote control.
2. Insert two AAA size
batteries. Close the
battery compartment
cover.
Install the batteries correctly by following the polarity
(+ and -) indications in the battery compartment.
3 3
Installing the Base Stand
screw
Screw A x 1
(P.N.: 209100412B1)
1. Lay the TV down on a at surface with the back side facing up.
Please make sure to place a soft cushioned material (such as a
pillow or thick piece of foam) beneath the screen.
2. Align the screw hole and then secure the base stand with the
provided 1 screw.
4 4
Connecting the Aerial
OR
RF coaxial cable
(not included)
PC RF INPUT
VGA INPUT
AC-INPUT AUDIO INPUT
100-240V~ 50/60Hz HDMI INPUT
VIDEO SCART
Connect one end of the RF coaxial cable to the aerial socket on
the wall and the other end of the cable to the RF IN (75 ) socket
on the right rear side of your TV.
Do not connect the TV to the mains supply until you
have completed all the connections.
6 6
Turning the TV On for the First Time
The rst time you turn the TV on, it will go straight into First Time Installation.
1. Press the OK button to
First Time Installation
start First Time Installation.
Please ensure aerial is plugged in!
Then press OK button.
3. Press the OK button to
Country
con rm UK as the country
UK Belgium Czech France Hungary
where you will operate the
TV.
Australia Bulgaria Denmark Germany Italy
Austria Croatia Finland Greece Luxembourg
OK
Well done,
your new TV is now ready to use. You will nd that there are many exciting features available. To get to know all these
features, please take some time to read the instruction manual provided with your TV.
If after reading the instruction manual you have additional questions related to the use of your TV please call our UK Call Centre on 0844 561 1234.
Our UK Customer Contact Centre is open Monday-Saturday 8am-8pm or Sunday 8am-6pm.
5 5
Connecting to the Mains Socket
To mains socket
1. Connect the mains cable to the mains socket after you have
completed all the connections.
2. At this stage, the TV switches to standby mode. The red LED
indicator will illuminate on the front panel of the TV.
3. In standby mode, press the button on the side panel of the
TV or on the remote control to turn the TV on. The red LED
indicator will turn green.
2. Press the OK button to
OSD Language
con rm English as your
Cesky English Magyar Polski
Fran ais
desired language to be
~
Dansk Espanol Hrvatski Nederlands Portugues
displayed on the menu.
Deutsch E k Italiano Norsk Pycck
OK
4. Channel tuning will
Channel Tuning
commence. This
operation may take up to
TV : 3 Channel(s) 6 minutes. The display
DTV : 0 Channel(s)
will show the progress of
Radio : 0 Channel(s)
the tuning and the
Date : 0 Channel(s)
number of channels
found.
36%... 668.75MHz (TV)
Please press MENU to skip.
(P.N.: 4033C221308)
