Table 1: IOM47 Physical Features Callouts and Descriptions
Callout Physical Feature Description
6 24 VAC, Class 2 Supply Power Terminal Block. (See
7 Cover Lift Tab (One of Two). (See
8 Sensor/Actuator (SA) Bus or Field Controller (FC) Bus Terminal Block. (See
9 Binary Input (BI) Terminal Block, 2 – Binary Inputs. (See
10 Universal Input (UI) Terminal Blocks, 6 – Universal Inputs. (See
11 End-of-Line (EOL) Switch. (See
Note: The EOL Switch is located under the controller cover. You must remove the cover to change the EOL switch
position.
12 LED Status Indicators. (See
13 Sensor Actuator (SA) Bus / Field Controller (FC) Bus Port (RJ-12 6-pin Modular Jack). (See
14 BO Terminal Block, 3 – Binary Outputs. (See
IOM4711 Input/Output Module Installation Instructions
Table
Removing the Controller
Setting the End-of-Line (EOL)
Table 8.)
Table 3.)
5.)
Cover.)
Table
Table 3.)
Table 3.)
Switch)
5.)
SA/FC Bus Port.)
4
