Digital Watchdog MEGApix DWC-MB45iALPRT User Manual page 34

Setup - Network Setup
FTP Settings
1
2
3
4
5
6
7
To transfer/save the image to the relevant sites through FTP, then FTP needs to be setup.
General Setting - Enable or disable the FTP function.
1
FTP Server Address - Define FTP Server IP Address. If the IP Address form is incorrect, a message box will be
2
shown to try again.
FTP Upload Path - Define a path in FTP server to store video. For the path name, English Alphabets,
3
numbers and special characters ( / ~ !@ $ ^ ( ) _ - { } [ ] ; , ) can be used.
FTP Port - Define the FTP Server Port. If the port is not appropriate, it is impossible to access to FTP Server.
4
User ID - Define User ID to access the FTP Server. Fill out the correct User ID registered in the FTP Server.
5
Password - Define Password to access the FTP Server. Fill out the correct Password registered in the FTP Server.
6
Click 'Apply' to save all settings.
7
Refer to the above image for example.
34
