Setup - Video & Audio Setup
Video Configuration
1
2
3
4
5
Live Video Channel Setup - The video can be configured to various settings with a combination of codec and
1
resolution. The camera performance should be considered when setting multiple channels, as the performance
of the camera will be affected.
H.265 (HEVC) codec with a higher bitrate may cause unstable live streaming or reload the webpage.
Codec - Choose the video codec. Depending on the selected codec, the subcategories may be changed
2
accordingly.
Description - Input the additional description of the selected channel. Max. 30 alphanumeric characters may
3
be used, including spaces.
Resolution - Select video resolution.
4
Available Frame Rate may differ even if the same codecs are in use.
<Resolution of Video Format>
QSXGA 3.7M
2560 x
2592 x
NTSC
1944
1440
2592 x 2560 x
PAL
1944 1440
Frame Rate - Select the maximum Frame Rate.
5
Available Frame Rate can be different although the same codecs were set up.
3M 0.3M 1080p/i
2304 x 1920 x
768 x 432 1280 x 720 800 x 600 640 x 480
1296 1080
2304 x 1920 x
768 x 432 1280 x 720 800 x 600 640 x 480
1296 1080
17
720p/i SVGA VGA
704 x 576
704 x 480
704 x 576
704 x 480
4CIF CIF
352 x 288
352 x 240
352 x 288
352 x 240
