Installation
STEP 2
Loosen retaining screw until
you can rotate main body
cover of the fan anticlockwise
to 'unlock position' and
remove cover
4
Installation
STEP 1
Connect ducting to the spigot on
the back of the Unity ZCV3si
Note: If using flexible ducting,
ensure this is pulled taut (to a
min. 90% stretch capacity)
between fan and termination
Lock position
Unlock position
Retaining screw
