Microsemi SmartFusion A2F500-DEV-KIT-2 Quick Start Manual

SmartFusion Development Kit
QSG0204 Quickstart Guide
Kit Contents – A2F500-DEV-KIT-2 (RoHS-compliant)
Quantity
1 SmartFusion
1 Low-cost programming stick (LCPS)
2 USB 2.0 A to mini-B Cable
1 5 V power supply with international adapters
Overview
The SmartFusion Development Kit offers a full-featured development board for SmartFusion
customizable system-on-chip (cSoC) devices. These are the only devices that integrate an FPGA,
®
ARM Cortex™-M3 microcontroller, and programmable analog, offering full customization, IP
protection, and ease-of-use.
The device contains on-chip flash and SRAM memory, as well as additional off-chip memory on the
board. The board also contains LEDs, switches, and various features for extensive analog
experimentation, including voltage rail monitoring, current POT, temperature diodes, and voltage
sweeping using active bipolar prescalers (ABPS). Networking interfaces include Ethernet PHY,
EtherCAT, CAN, UART, and RS485.
Jumpers and Switch Settings
Jumpers and switches are set during the manufacturing and test of the development board. To
confirm settings, review the
are open.
© 2015 Microsemi Corporation. All rights reserved.
®
Development board with A2F500M3G-FGG484ES
"Running the Manufacturing
Description
Test". Any jumper connectors not noted
