Microsemi SmartFusion Quick Start Card

SmartFusion Development Kit
Quickstart Card
Kit Contents – A2F500-DEV-KIT-2 (RoHS-compliant)
Quantity
1 SmartFusion
1 Low-cost programming stick (LCPS)
2 USB 2.0 A to mini-B Cable
1 5 V power supply with international adapters
Overview
The SmartFusion Development Kit offers a full-featured development board for SmartFusion
customizable system-on-chip (cSoC) devices. These are the only devices that integrate an FPGA,
®
ARM Cortex™-M3, and programmable analog, offering full customization, IP protection, and
ease-of-use.
The device contains on-chip flash and SRAM memory, as well as additional off-chip memory on the
board. The board can communicate via Ethernet and HyperTerminal. The board also contains LEDs,
switches, OLED, and extensive analog experimentation, including voltage rail monitoring, current
POT, temperature diodes, and voltage sweeping using active bipolar prescalers (ABPS). Networking
interfaces include Ethernet PHY, EtherCAT, CAN, UART, and RS485.
Jumpers and Switch Settings
Jumpers and switches are set during the manufacturing and test of the development board. To
confirm settings, review the
are open.
© 2012 Microsemi Corporation. All rights reserved.
®
Development board with A2F500M3G-FGG484ES
"Running the Manufacturing
Description
Test". Any jumper connectors not noted
