Summary of Contents for Lumberjack XP Series
- Page 1 LRH755 Original Manual SDS Rotary Hammer Drill Read this manual before using this product. Failure to do so can result in serious injury. SAVE THIS MANUAL.
- Page 2 Rotary Hammer Drill Owner’s Manual & Safety Instructions INDEX 1 - 3. Power Tool & Personal Safety Symbols & Technical Includes Assembly Operation Maintenance & Service Declaration...
- Page 3 Rotary Hammer Drill Owner’s Manual & Safety Instructions General Power Tool Safety Warnings : Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term ″...
- Page 4 Rotary Hammer Drill Owner’s Manual & Safety Instructions :The term residual current device (RCD) may be replaced by the term ground fault circuit interrupter (GFCI) or earth leakage circuit breaker (ELCB). Personal Safety a. Stay alert, watch what you are doing and use common sense when operating a power tool.
- Page 5 Rotary Hammer Drill Owner’s Manual & Safety Instructions power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. d. Store idle power tools out of the reach of children and do not allow persons un- familiar with the power tool or these instructions to operate the power tool.
-
Page 6: Technical Data
Rotary Hammer Drill Owner’s Manual & Safety Instructions Service Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. 6. Symbols a. Some of the following symbols may appear on this product. Study these symbols and learn their meanings. - Page 7 Rotary Hammer Drill Owner’s Manual & Safety Instructions Includes: 1. Dust shield 2. Locking sleeve 3. Built in work linght 4. Hammer drill selec�on dial 5. Variable speed controlled switch 6. Forward /reverse lever & trigger lock 7. Rubberised grip 8.
-
Page 8: Installing Accessories
Rotary Hammer Drill Owner’s Manual & Safety Instructions Assembly: WARNING Disconnect ba�ery pack from tool or place the switch in the locked or off posi�on before making any assembly, adjustments or changing accessories. Such preven�ve safety measures reduce the risk of star�ng the tool accidentally. -
Page 9: Operation
Rotary Hammer Drill Owner’s Manual & Safety Instructions Operation: VARIABLE SPEED CONTROLLED TRIGGER SWITCH Your tool is equipped with a variable speed trigger switch. The tool can be turned “ON” or “OFF” by squeezing or releasing the trigger. The speed can be adjusted from the minimum to maximum by the pressure you apply to the trigger. -
Page 10: Maintenance
Rotary Hammer Drill Owner’s Manual & Safety Instructions Maintenance: WARNING: Before any work on the machine itself, remove the ba�ery pack from the drill. 1.Inspect bolts periodically. If the bolts loosen, �ghten them immediately, or will result in serious accident. 2.Inspect tool cords periodically. -
Page 11: Ce Declaration Of Conformity
Rotary Hammer Drill Owner’s Manual & Safety Instructions CE DECLARATION OF CONFORMITY TOOLSAVE Unit C, Manders Ind. Est., Old Heath Road, Wolverhampton, WV1 2RP. Tel: 01902 450 470 Declares that the SDS Rotary Hammer Drill (LRH755) Is in co mpliance with the regulations included in the Directives:2006/42/EC EC DECLARATION OF CONFORMITY Certifica te for EC-type examination delivered by Intertek Testing Services... - Page 12 Rotary Hammer Drill Owner’s Manual & Safety Instructions...
- Page 13 UNIT C MANDERS INDUSTRIAL ESTATE, OLD HEATH ROAD, WOLVERHAMPTON www.Lumberjacktools.co.uk...
