Lumberjack XP Series Original Manual
Mini plunge saw
Hide thumbs
Also See for XP Series:
- Owner's manual (18 pages) ,
- Original manual (17 pages) ,
- Owner's manual & safety instructions (14 pages)
Subscribe to Our Youtube Channel
Related Manuals for Lumberjack XP Series
Summary of Contents for Lumberjack XP Series
- Page 1 LPS89L Original Manual Mini Plunge Saw Read this manual before using this product. Failure to do so can result in serious injury. SAVE THIS MANUAL.
- Page 2 Mini Plunge Saw Owner’s Manual & Safety Instructions INDEX 1 - 3. Power Tool & Personal Safety Symbols & Technical Includes Assembly Operation Maintenance & Service Declaration...
- Page 3 Mini Plunge Saw Owner’s Manual & Safety Instructions General Power Tool Safety Warnings : Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term ″...
- Page 4 Mini Plunge Saw Owner’s Manual & Safety Instructions :The term residual current device (RCD) may be replaced by the term ground fault circuit interrupter (GFCI) or earth leakage circuit breaker (ELCB). Personal Safety a. Stay alert, watch what you are doing and use common sense when operating a power tool.
- Page 5 Mini Plunge Saw Owner’s Manual & Safety Instructions power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. d. Store idle power tools out of the reach of children and do not allow persons un- familiar with the power tool or these instructions to operate the power tool.
-
Page 6: Technical Data
Mini Plunge Saw Owner’s Manual & Safety Instructions Service Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. 6. Symbols a. Some of the following symbols may appear on this product. Study these symbols and learn their meanings. - Page 7 Mini Plunge Saw Owner’s Manual & Safety Instructions Includes: Saw Blade Base Plate Dust Extraction Port Upper Blade Guide Rip Guide Vacuum Adaptor Blade Wrench Rip Guide Locking Screw Blade Bolt & Washer Lock Off Button On/Off Switch Depth Guide Bracket Depth Dial Spindle Lock Button...
- Page 8 Mini Plunge Saw Owner’s Manual & Safety Instructions Assembly: Mounting the Saw Blade Clean the saw blade and all clamping parts to be assembled. Press the Lock off button, then adjust the base plate to the maximum cutting depth and keep it there. Put the saw blade on the spindle.
-
Page 9: Operation
Mini Plunge Saw Owner’s Manual & Safety Instructions Operation: Install the Rip Guide To install the rip guide on the machine, perform the following steps. Remove battery from your plunge saw. lnsert the rip guide through all three slots on the base plate at the front of the saw, starting with slot in the left side edge of the base. -
Page 10: Maintenance
Mini Plunge Saw Owner’s Manual & Safety Instructions Maintenance: WARNING: Before any work on the machine itself, remove the ba�ery pack from the drill. 1.Inspect bolts periodically. If the bolts loosen, �ghten them immediately, or will result in serious accident. 2.Inspect tool cords periodically. -
Page 11: Ce Declaration Of Conformity
Mini Plunge Saw Owner’s Manual & Safety Instructions CE DECLARATION OF CONFORMITY TOOLSAVE Unit C, Manders Ind. Est., Old Heath Road, Wolverhampton, WV1 2RP. Tel: 01902 450 470 Declares that the Mini Plunge Saw (LPS89L) Is in co mpliance with the regulations included in the Directives:2006/42/EC EC DECLARATION OF CONFORMITY Certifica te for EC-type examination delivered by Intertek Testing Services... - Page 12 Mini Plunge Saw Owner’s Manual & Safety Instructions...
- Page 13 UNIT C MANDERS INDUSTRIAL ESTATE, OLD HEATH ROAD, WOLVERHAMPTON www.Lumberjacktools.co.uk...
