- Page 1 EN Installation / User Instructions / Warranty FR Instructions de montage / Mode d'emploi / Garantie ES Instrucciones de montaje / Manejo / Garantía Metris 14820XX1 04508XX0...
-
Page 2: Technical Information
English Français Technical Information Données techniques Water pressure Pression d’eau Recommended 15 - 75 PSI (0.1 - 0.5 MPa) recommandée 15 - 75 PSI (0.1 - 0.5 MPa) Maximum 145 PSI (1 MPa) maximum 145 PSI (1 MPa) Hot water temp. Température d'eau chaude Recommended 120°-140°... - Page 3 Español Datos tecnicos Tools Required / Outils Requis / Herramientas Útiles Presión en servicio recomendada 15 - 75 PSI (0.1 - 0.5 MPa) max. 145 PSI (1 MPa) Temperatura del agua caliente recomendada 120°-140° F (48° - 60° C)* 9 mm max.
- Page 4 Metris Metris 14820XX1 04508XX0 11⅛" (282 mm) 9⅜" (237 mm) 7⅜" (187 mm) Ø 1⅛" (30 mm) 2½" (62 mm) 4¾" (121 mm) 4¾" (121 mm) 3⅛" 3⅛" (79 mm) (79 mm) 2¼" 2¼" (57 mm) (57 mm) Ø1⅜" Ø1⅜" (34 mm) (34 mm) ⅜...
- Page 5 Optional: Adjust the spout rotation / En Option : Ajustez la Rotation du Bec / Opcional: Ajuste la Rotación del Surtidor 150° 75° 75° 24 x 15° 105° 45° 105° 45°...
- Page 6 Optional: Adjust the spout rotation / En Option : Ajustez la Rotation du Bec / Opcional: Ajuste la Rotación del Surtidor 110° 55° 55° 24 x 15° 85° 25° 85° 25°...
-
Page 7: Installation / Installation / Instalación
Installation / Installation / Instalación Place the faucet and sealing ring on the mounting surface. Install the plastic washer, friction washer, metal washer, and mounting nut. If the mounting surface is thicker than 1¾", or if there is insufficient space, omit the plastic washer. Placez l'anneau d'étanchéite et le robinet sur la surface de montage. - Page 8 Connect the hot and cold supply hoses to the stops. Use two wrenches. Do not allow the supply hoses to twist. Connectez les tuyaux d'arrivée d'eau chaude et d'eau froide aux tuyau d'alimentation. Servez-vous de deux clés, tel qu'illustre dans le schema. Assurez-vous que les tuyaux n'sentortillent pas.
- Page 9 Install the hose weight. Test the handspray hose. If it does not retract smoothly, reposition the weight. Installez le contrepoids sur le tuyau. Tirez sur la douchette. Elle devrait coulisser facilement et se rétracter sans à-coups. Modifiez la position du contrepoids au besoin.
- Page 10 Install the filter in the handspray hose. Lightly lubricate the hose o-ring. Installez le filtre dans le tuyau flexible. Lubrifiez le joint torique du tuyau. Instale el filtro en la manguera. Lubrique ligeramente la junta tórica de la manguera. Install the handspray. Tighten the hose nut. 0.7 ft-lb 1 Nm Installez le douchette.
- Page 11 Set hot water limiter / Positionner le limiteur de température / Ajustar tope 140 °F 50 °F 44 PSI 60° C 10° C 0.3 Mpa 4 mm 100ºF 38ºC 95ºF 140ºF 36ºC 122ºF 60ºC 50ºC 131ºF 108ºF 55ºC 43ºC 17 x 4 mm 3.7 ft-lb 4 mm...
- Page 12 Replacement Parts / Pièces détachées / Repuestos Metris HighArc 2-Spray Pull-Out 14820XX1 Metris Prep 2-Spray Pull-Out 98127000 04508XX0 (11x2) 92755000 97735000 96737000 95340000 98491XX0 14820XX1 only (110°/150°) 98492XX1 98455XX0 96338000 98193000 98365000 (32x2) 95140000 98211000 95008000 (21x2.5) 95498XX0 97209000 92730000 96316001 97523000 97548000...
- Page 13 User Instructions / Instructions de service / Manejo ouvert fermé abierto cerrar cold chaud froid caliente frío...
- Page 14 Cleaning / Nettoyage / Limpieza Check valve maintenance / Entretien de les clapets anti-retour/ Mantenimiento de las válvulas antirretornos...
-
Page 15: For Best Results
Cleaning Recommendation for Hansgrohe Products Modern bathroom faucets, kitchen faucets and shower products are made from different materials to comply with the needs of the market with regard to design and functionality. To avoid damage to the product, it is necessary to take proper care of it. For best results: •... -
Page 16: Para Obtener Mejores Resultados
Important • Les residus de produits pour le corps comme les savons liquides, shampooings, gels de douche, teintures pour cheveux, parfums, apres-rasage et vernis a ongles peuvent causer des deteriorations. Rincez le produit avec de l’eau propre après chaque utilisation. •... - Page 19 Hansgrohe, Inc. Limited Warranty Offering our customers the highest quality at all times is a fundamental • abuse, neglect or improper or incorrectly performed instal- part of the Hansgrohe, Inc. company philosophy. We offer consumers lation, maintenance or repair, including the use of abrasive a limited warranty on our hansgrohe and AXOR branded products.
- Page 20 FROM REASONABLE WEAR AND TEAR, OUTDOOR USE, MISUSE This warranty gives you specific legal rights, and you may also have (INCLUDING USE OF THE PRODUCT FOR AN UNINTENDED other rights which vary from state to state. APPLICATION), FREEZING WATER, EXCESSIVE WATER PRESSURE, PROD UCT I NSTRUC TI ON S A ND Q U ESTI O NS PIPE CORROSION IN THE HOME IN WHICH THE PRODUCT IS INSTALLED, ABUSE, NEGLECT OR IMPROPER OR INCORRECTLY...
