ASM L2100 Plus Operation

Electric airless sprayer
Hide thumbs Also See for L2100 Plus:
Table of Contents

Advertisement

Quick Links

Download this manual
Operation
Electric Airless Sprayer
- For portable spray applications of architectural paints and coatings -
- For professional use only -
- Not approved for use in explosive atmospheres or hazardous locations -
Stand Models
ASM L2100 Plus 230V: 24U099
ASM L2100 Plus 110V: 24U100
Hi-Boy Models
ASM L2100 Plus 230V: 24U101
3300 psi (22,7 MPa, 227 bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this manual and on the
unit, including the power cord. Save these instructions.
ti22209a
Hi-Boy
ti22210a
Stand
332761A
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L2100 Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASM L2100 Plus

Summary of Contents for ASM L2100 Plus

  • Page 1 - For portable spray applications of architectural paints and coatings - - For professional use only - - Not approved for use in explosive atmospheres or hazardous locations - Stand Models ASM L2100 Plus 230V: 24U099 ASM L2100 Plus 110V: 24U100 Hi-Boy Models ASM L2100 Plus 230V: 24U101...

  • Page 2: Table Of Contents

    Notes ....... .19 ASM Standard Warranty ....20...

  • Page 3: Warnings

    Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable.
  • Page 4 Warnings WARNING WARNING WARNING WARNING FIRE AND EXPLOSION HAZARD Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help prevent fire and explosion: • Do not spray flammable or combustible materials near an open flame or sources of ignition such as cigarettes, motors, and electrical equipment.
  • Page 5 Warnings WARNING WARNING WARNING WARNING EQUIPMENT MISUSE HAZARD Misuse can cause death or serious injury. • Always wear appropriate gloves, eye protection, and a respirator or mask when painting. • Do not operate or spray near children. Keep children away from equipment at all times. •...
  • Page 6 Warnings WARNING WARNING WARNING WARNING TOXIC FLUID OR FUMES HAZARD Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or swallowed. • Read MSDSs to know the specific hazards of the fluids you are using. •...

  • Page 7: Component Identification (Hi-Boy Models)

    Component Identification (Hi-Boy Models) Component Identification (Hi-Boy Models) ti22418a Trigger Lock ON/OFF Switch Drain Hose Pressure Gauge Suction Hose Prime Valve Pump Model/Serial Tag Pail Hook Guard Fluid Outlet Filter Power Cord Pressure Control Fluid Hose 332761A...

  • Page 8: Component Identification (Stand Models)

    Component Identification (Stand Models) Component Identification (Stand Models) ti22419a Fluid Hose ON/OFF Switch Trigger Lock Pressure Control Drain Hose Pressure Gauge Suction Hose Prime Valve Pump Model/Serial Tag Fluid Outlet Guard Filter Power Cord 332761A...

  • Page 9: Pressure Relief Procedure

    Pressure Relief Procedure Pressure Relief Procedure Follow the Pressure Relief Procedure whenever 5. Engage the trigger lock. you see this symbol. 6. Turn prime valve down. Have a waste container ready to catch drainage. Leave drain valve open until you are ready to spray again. This equipment stays pressurized until pressure is manually relieved.

  • Page 10: Grounding

    Grounding Grounding The sprayer cord includes a grounding wire with an appropriate grounding contact. The equipment must be grounded to reduce the risk of static sparking and electric shock. Electric or static sparking can cause fumes to ignite or explode. Improper grounding can cause electric shock.

  • Page 11: Pails

    Grounding Pails Solvent and oil/based fluids: follow local code. Use To maintain grounding continuity when flushing or only conductive metal pails, placed on a grounded sur- relieving pressure: hold metal part of spray gun firmly face such as concrete. to side of a grounded metal pail. Then trigger gun. Do not place pail on a nonconductive surface such as paper or cardboard which interrupts grounding continuity.

  • Page 12: Setup

    Setup Setup 6. Fill throat packing nut with ASM Packing Seal to prevent premature packing wear. Do this each time you spray. 1. Connect ASM airless hose to sprayer. Tighten securely. ti9040a 7. Turn power OFF. ti5316a ti10308b 2. Connect other end of hose to gun.

  • Page 13: Startup

    Startup Startup High-pressure spray is able to inject toxins into the 1. Turn pressure control to lowest pressure. body and cause serious bodily injury. Do not stop leaks with hand or rag. 6. Inspect for leaks. If leaks occur, perform Pressure Relief, page 9.

  • Page 14: Spray Test Pattern

    Startup Spray Test Pattern Clearing Clogs 1. Spray test pattern. Adjust pressure to eliminate heavy edges. 1. Release trigger. Engage trigger lock. Rotate Spray Tip. Disengage trigger lock. Trigger gun at waste area to clear clog. Heavy Edges ti2757a 2. Use smaller tip size if pressure adjustment cannot ti9046a ti9047a ti10315a...

  • Page 15: Cleanup

    Cleanup Cleanup 6. Hold gun against paint pail. Disengage trigger lock. Trigger gun and increase pressure until the pump runs steady and flushing fluid appears. 1. Relieve Pressure, page 9. 2. Remove guard and Spray Tip. For additional infor- mation, see separate gun manual. ti10313a 7.
  • Page 16 Cleanup 10. Close drain valve. Trigger gun into flushing pail to 14. Remove filter from gun if installed. Clean and purge fluid from hose. inspect. Install filter. See separate gun manual. ti8327a Flush ti10312a 11. Turn pressure control knob all the way down and power switch OFF.

  • Page 17: Technical Specifications

    Technical Specifications Technical Specifications Electric Airless Sprayers 24U101, 24U099, 24U100 Metric Sprayer 100/120V AC, 50/60 Hz, 11 A, 1 phase Power requirements 230V AC, 50/60 Hz, 7.5 A, 1 phase Generator required 3000 W minimum Maximum working pressure 3300 psi 227 bar, 22.7 MPa Cycles per gallon (liter)* Maximum delivery...

  • Page 18: Notes

    Notes Notes 332761A...

  • Page 19: Notes

    Notes Notes 332761A...

  • Page 20: Asm Standard Warranty

    ASM, ASM will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by ASM to be defective. This warranty applies only when the equipment is installed, operated and maintained in accordance with ASM’s written recommendations.
