3 About
3.4 Nexus Q specification
Frequency response
Effciency 1
Nominal impedance
Power handling
2
Maximum output
3
Driver configuration
Dispersion
Connectors
Height
Width
Depth
Weight
1 Measured in half space 2 AES2 - 1984 compliant

3.5 Nexus Q dimensions

738 (29")
738 (29")
738 (29")
UG10576-2.0 - Nexus Q User Guide V2.0
60 Hz - 150 Hz ±3 dB
110 dB 1W/1m
2 x 4 Ω
2 x 2000 W AES
145 dB cont, 151 dB peak
4 x 12"
Array dependant
2 x 4-pole speakON™
754 mm (29.7")
738 mm (29")
860 mm (33.9")
130 kg (286.6 lbs)
3 Calculated
860 (33.9") 738 (29")
Figure 3.1: Dimensions
