- Page 1 Nexus X Impressively efficient, omnipotent audio U S E R G U I D E V 2 . 0...
- Page 2 For the latest online version, visit: www.voidacoustics.com Void Acoustics and the Void logo are registered trademarks of Void Acoustics Research Ltd. in the United Kingdom, USA and other countries; all other Void trademarks are the property of Void Acoustics Research Ltd.
-
Page 3: Table Of Contents
Nexus X Specifications Nexus X Dimensions Cable and Wiring Electrical Safety Cable Considerations for Fixed Installations Nexus X Wiring Diagram Bias Q5 speakON™ Wiring Service Return Authorisation Shipping and Packing Considerations Appendix UG10577-2.0 - Nexus X User Guide V2.0 Page 3... -
Page 4: Safety And Regulations
Void Acoustics Research Ltd for such as when the power-supply cord or plug is damaged, liquid reprocessing. -
Page 5: Unpacking And Checking
When you are removing your Nexus X loudspeaker from its original packaging: • Nexus X loudspeakers come packaged in a lid and base carton that has a protective sleeve around it; avoid using sharp implements to remove the cardboard to protect the finish •... -
Page 6: About
3.2 Nexus X overview The 8000 Watt Nexus X serves the lower spectrum of the Nexus LF system. It does this with unmatched displacement via its eight 12” transducers, each capable of extreme amounts of excursion with very low distortion. -
Page 7: Nexus X Specifications
18 mm birch plywood Finish Textured ‘TourCoat’ polyurethane Grille Perforated Steel Measured in half space AES2 - 1984 compliant Calculated 3.5 Nexus X dimensions 861 (33.9”) 739 (29.1”) Figure 3.1: Dimensions UG10577-2.0 - Nexus X User Guide V2.0 Page 7... -
Page 8: Cable And Wiring
Out/Link 12” LF 12” LF 12” LF 12” LF Figure 4.1: Wiring diagram speakON pins 1+/1- speakON pins 2+/2- LF (4 x 12”) LF (4 x 12”) LF link LF link UG10577-2.0 - Nexus X User Guide V2.0 Page 8... -
Page 9: Bias Q5 Speakon™ Wiring
Channel 1 and 2 (bridged) Channel 3 and 4 (bridged) Output LF (4 x 12”) LF (4 x 12”) 1 (4 Ω load to amplifier) 1 (4 Ω load to amplifier) Max parallel units UG10577-2.0 - Nexus X User Guide V2.0 Page 9... -
Page 10: Service
5.2 Shipping and packing considerations • When sending a Void Nexus X loudspeaker to an authorised service centre, please write a detailed description of the fault and list any other equipment used in conjunction with the faulty product. -
Page 11: Appendix
The external dimensions of the enclosure shall be (H) 746 mm x (W) 738 mm x (D) 860 mm (29.4” x 29” x 33.9”). Weight shall be 137 kg (302 lbs). The loudspeaker shall be the Void Acoustics Nexus X. UG10577-2.0 - Nexus X User Guide V2.0... - Page 12 H E A D O F F I C E Void Acoustics Research Ltd, Unit 15, Dawkins Road Industrial Estate, Poole, Dorset, BH15 4JY United Kingdom Call: +44(0) 1202 666006 Email: info@voidacoustics.com voidacoustics.com Void Acoustics Research Limited is a company registered in England and Wales registration number 07533536...
