5 Adjustments

To avoid damage when making adjustments please note the following:
• Removing the grille can cause debris to collect within the enclosure, take care
to remove anything that may have collected internally
• Do not use impact tools.

5.1 Wheel removal

Step 1:
Remove all four M6 bolts with a 13 mm
spanner/wrench.
Step 2:
Remove/add the wheels and keep in a safe
place. Repeat the process for the other three
wheels.
Step 3:
Replace the M8 bolts by hand until finger tight
before using hand tools.
Note: Replacing bolts is of particular
importance as without them there
can be air leakage and detuning.
UG10576-2.0 - Nexus Q User Guide V2.0
Figure 5.1: Bolt removal
Figure 5.2: Wheel removal
Figure 5.3: Bolt tightening
Page 11
