At-6 texan EP
Requires : 5-channel radio w/ 5 micro servos,
Wing Span
Wing Area
Flying Weight
Fuselage Length
Warning ! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
The World Models
Manufacturing Co., Ltd.
www.theworldmodels.com
E269XMPO24481007
All manuals and user guides at all-guides.com
Outrunner Motor KM0283010
w/ Propeller Adaptor HW2340100,
20A brushless ESC, 3 cells 11.1V
2100 mAh Li - Po battery & charger.
S p ecifica tio n s
* Specifications are subject to change without notice.*
INSTRUCTION MANUAL
44 in / 1120 mm
295 sq in / 19 sq dm
31 oz / 870 g
31.5 in / 800 mm
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
Advertisement
Table of Contents
Related Manuals for TWM AT-6 TEXAN EP
Summary of Contents for TWM AT-6 TEXAN EP
- Page 1 All manuals and user guides at all-guides.com INSTRUCTION MANUAL At-6 texan EP Requires : 5-channel radio w/ 5 micro servos, Outrunner Motor KM0283010 w/ Propeller Adaptor HW2340100, 20A brushless ESC, 3 cells 11.1V 2100 mAh Li - Po battery & charger.
-
Page 2: Before You Begin
All manuals and user guides at all-guides.com At-6 texan EP INDEX BEFORE YOU BEGIN PARTS LIST ASSEMBLY P.3-P.10 SAFETY PRECAUTIONS P.10 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. - Page 3 All manuals and user guides at all-guides.com Parts List 1. MAIN WING -- 1 pc. 10. SOCKET HEAD SCREW M2.5x8mm -- 4 pcs WASHER d3xD7mm -- 8 pcs 2. RETRACTABLE LANDING GEAR -- 1 pair SCREW PM3x6mm -- 4 pcs MAIN WHEEL Ø40mm -- 2 pcs FOLDING PROPELLER SET (10x6) -- 1 set RETRACTABLE LANDING GEAR COVER -- 2 sets...
-
Page 4: Retractable Landing Gear
All manuals and user guides at all-guides.com Main Wing Apply instant type CA glue to both sides of each hinge. Aileron Servo Lead Bottom View Aileron Servo Lead Completed Retractable Landing Gear Bottom View E269XMPO24481007... -
Page 5: Retract Servo
Ø1mm pilot holes for World Models horn are pre-drilled. Aileron Servo Please look for pin-hole marks at under side of control surfaces. PB2x16mm Screw PA1.7x8mm Fuel Tube Straper d2xD4x4mm PA1.7x8mm Screw TWM PL8210010 CLEVIS WRENCH Bottom View Fuel Tube PB2x12mm d2xD4x4mm Clevis Pushrod Ø1.4x48.5mm Horn Please choose either 02L &... -
Page 6: Stabilizer & Elevator
All manuals and user guides at all-guides.com Stabilizer & Elevator PB2x8mm Screw Apply instant type CA glue to both sides of each hinge. A=A' Balsa 4x11.9x24mm PB2x8mm Ø1mm pilot holes for World Models horn are pre-drilled. Please look for pin-hole marks at under side of control surfaces. -
Page 7: Tail Landing Gear
M2 Nut Aluminum Plate 0.3mm Bottom View Ø1mm pilot holes for World Models horn are pre-drilled. Rudder Pushrod Please look for pin-hole marks at under side of control surfaces. PB2x8mm Screw TWM PL8210010 38mm 100mm CLEVIS WRENCH Horn Pushrod Ø1.4x414mm... - Page 8 KM0283010 wirings or anything. PM3x6mm d3xD7mm Washer Propeller Adaptor (d3xD5) 25A Brushless ESC HW2340100 TWM KC2025A02A PM2x12mm PM2x12mm Don’t over-tighten the PM2 screws, let the propeller blades align themselves when spinning. 1.5mm PWA2x8mm M5 Nut M5 Nut Spinner Nut Ø15x25mm...
-
Page 9: Radio Equipment
All manuals and user guides at all-guides.com Radio Equipment Fuel Tube Front Rudder Servo Sponge d2xD4x4mm Rudder Pushrod Elevator Pushrod Straper Battery Tie Elevator Servo Bottom View 20A Brushless ESC Sponge Receiver Front Battery Completed Main Wing PM2.5x20mm Front Nylon Bolt d2.6xD9mm Nylon Washer 2.5mm... - Page 10 All manuals and user guides at all-guides.com Canopy PWA2x8mm Screw Pilot Canopy 1.5mm PWA2x8mm Carb Intake Wing Setting Adjust the wing and fuselage configuration as shown in the diagrams. A=A' B=B' C=C' E269XMPO24481007...
-
Page 11: Control Throws
# First time flyer should never fly by himself / herself. Assistance from experienced flyer is absolutely necessary. # Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted aircraft. At-6 texan EP is specially designed to be powered by KM0283010 Outrunner Motor. - Page 12 All manuals and user guides at all-guides.com Ｐａｔｔｅｒｎ Ｄｕｃｔｅｄ Ｆａｎ Ｆｕｎｆｌｙ Ｗａｒｂｉｒｄｓ Ｓｃａｌｅ Ｅｌｅｃｔｒｉｃ Ｓｐｏｒｔｓ Ｇｌｉｄｅｒ Ｂｏａｔ Ｔｒａｉｎｅｒ Ａｃｃｅｓｓｏｒｉｅｓ Ｃｏｖｅｒｉｎｇ （Ｌｉｇｈｔｅｘ ／ Ｔｏｕｇｈｌｏｎ） The World Models Manufacturing Co., Ltd. www.theworldmodels.com E269XMPO24481007...
