TWM P-51 MUSTANG 60 Instruction Manual

0.60-0.75 cu.in. displacement 2-stroke 0.91 cu.in. displacement 4-stroke
Hide thumbs
Table of Contents

Advertisement

Quick Links

P-51 MUSTANG 60
0.60-0.75 cu.in. displacement 2-stroke
0.91 cu.in. displacement 4-stroke
Requires: 6-channel radio w/ 6 standard servos
Wing Span
Wing Area
Flying Weight
Fuselage Length
*Specifications are subject to change without notice.*
Warning! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
The World Models
Manufacturing Co
www.theworldmodels.com
Specifications
., Ltd .
INSTRUCTION MANUAL
64.5 in / 1640 mm
755 sq in / 48.7 sq dm
8.4 Ib / 3700 g
56.0 in / 1430 mm
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY(ARF) SERIES
ARF
MADE IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P-51 MUSTANG 60 and is the answer not in the manual?

Questions and answers

Related Manuals for TWM P-51 MUSTANG 60

Summary of Contents for TWM P-51 MUSTANG 60

  • Page 1 INSTRUCTION MANUAL P-51 MUSTANG 60 0.60-0.75 cu.in. displacement 2-stroke 0.91 cu.in. displacement 4-stroke Requires: 6-channel radio w/ 6 standard servos Specifications Wing Span 64.5 in / 1640 mm Wing Area 755 sq in / 48.7 sq dm Flying Weight 8.4 Ib / 3700 g Fuselage Length 56.0 in / 1430 mm...

  • Page 2: Before You Begin

    P-51 MUSTANG 60 I N D E X BEFORE YOU BEGIN P. 1 PARTS LIST P. 2 ASSEMBLY P. 3 -11 SAFETY PRECAUTIONS P.11 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do.

  • Page 3: Parts List

    Parts List 1.MAIN WING -- 1 pair PLYWOOD 7x7x58mm(For Fire Box) -- 2 pcs BALSA 11x31x123mm(For Fire Box) -- 1 pc 2.WING TUBE Ø16x595mm -- 1 pc. 13. FUEL TANK 380cc -- 1 set 3.SCREW PM2x6mm -- 12 pcs DOUBLE-SIDED TAPE 40x100mm -- 1 pc. M2 NUT -- 12 pcs CABLE TIE 1.5x5x400mm -- 1 pc.
  • Page 4 Main Wing Pre-glued Bottom View Main Wing Please apply glue to all surfaces of wing joiner Wing Tube Ø16x595mm Down Completed Make sure to glue securely. If not properly glued, a failure in fight may occur.

  • Page 5: Retractable Landing Gear

    Ø6x5mm 1.5mm Tri-horn Pushrod Ø1.8x87mm M3 x 14mm(L) Elevator Pushrod TWM Pl8210010 Ø1.8x 87mm CLEVIS WRENCH PWA 2 x 8mm Completed Ø1mm pilot holes for World Models tri-horn are pre-drilled. Please look for pin-hole marks at under side of control surfaces.

  • Page 6: Stabilizer & Elevator

    Flap and Retract Servo TWM Pl8210010 CLEVIS WRENCH Straper Fuel Tube Ø6x5mm Flaps up Flaps Down Y Rod Ø1.8 x 110mm Clevis Lead to retract servo Ring Lead to Flap servo Lead to Aileron servo (Stabilizer) Temporary install the main wing, adjust Stabilizer &...

  • Page 7: Tail Landing Gear

    PB 2 x 16 mm Screw PB 2 x 14 mm PB 2 x 14mm PB 2 x 16mm Fuel Tube Ø6x5mm TWM Pl8210010 CLEVIS WRENCH Tri-horn Ø1mm pilot holes for World Models tri-horn are pre-drilled. M3 x 22mm(L) Elevator Pushrod Ø1.8x560mm Please look for pin-hole marks at under side of control surfaces.

  • Page 8: Engine Mount

    Elevator & Rudder Pushrod Elevator Pushrod Rudder Pushrod Completed Bottom View Engine Mount Socket Head Screw Socket Head Screw M4 x 25mm M4 x 25mm Washer d4.2 x D14.5mm Washer d4.2 x D14.5mm Apply thread locker to screws Engine Mount Blind nuts are off-centered PL5911080 to keep the spinner at the...

  • Page 9: Fuel Tank

    Cable Tie Fuel Tank 1.5x5x400mm Battery Cover Double-sided Tape 40x100mm M4 Nylon Insert Lock Nut Washer d4 x D12mm Engine Socket Head Screw M4x35mm Screw KM3x20mm M4 Nylon Insert Lock Nut Socket Head Screw M3 Nylon Insert Lock Nut M4 x 35mm Washer d4 x D12mm ANTI-VIBRATION MOUNT INSTALLATION...
  • Page 10 Servo Set Set Screw 3 x 3mm Linkage Connector Throttle Pushwire Washer M2 Nut Throttle Servo. Please refer to attached sheet for linkage connector installation. Servos Install and arrange the servo as shown in the diagram. Rudder Pushrod Fuel Tube Ø1.8x710mm Ø6x5mm Balsa...
  • Page 11 Main Wing Screw Screw HM4 x 40mm HM4 x 40mm Washer d4.2x D14.5mm Screw PWM2.5 x 12mm Wing Protection Washer 2 x 20 x 95mm d4.2x D14.5mm PWM2.5 x 12mm Completed Canopy Screw PWA2.3 x 12 mm Silicon Grommet d1.5 x D6.5 mm Apply double-sided tape PWA2.3 x12 mm Silicon Grommet...
  • Page 12 Cowling Please refer to the attached sheet for usage of the transparent 3D template. First insert the grommet to the cowling then apply screw. Screw PWA2.6 x 12 mm Silicon Grommet d1.5 x D6.5 mm Spinner Ø102mm Fuselage Silicon Grommet d1.5xD6.5mm PWA2.6x12mm Cowling...

  • Page 13: Control Throws

    Pre - flight adjustment must be done before flying, it is very dangerous to fly a badly pre - adjusted aircraft. P-51 MUSTANG 60 is specially designed to be powered by 2C 0.61-0.75 or 4C 0.91 glow engine, using a more powerful engine does not mean better performance. In fact, over powered engine may cause severe damage and injuries.
  • Page 14 Usage of the transparent 3D template This transparent 3D template is used for position guidance of the actual cutting of the pre-painted cowling. Simply cut the transparent 3D template to fit your engine and exhaust pipe, then slide onto the actual cowling and use as template to mark the openings required for final cutting.
  • Page 15 LINKAGE CONNECTOR HW7111050 & HW7111060 Drill 2mm hole at servo horn. Insert linkage connector into servo horn. Make sure shoulder of screw is cleared from servo horn. Add washer to reduce play if necessary. Shoulder Tighten up the round nut against the shoulder.
