Summary of Contents for SGM Flasher DMX 1.5
- Page 1 Flasher D D MX 1.5 professional strobe projector rel. 1.00 user manual...
- Page 2 • The minimum distance between the projector and the surface to be illuminated must not be less than 1.5 m. • In case of serious functioning problems, switch off the equipment and contact the nearest SGM retailer or the manufacturer directly for inspection.
- Page 3 Cleaning the fixture / periodic checks Switching the fixture on / fixture status Start addresses Connecting the Flashers Control channels ch 1 - dimmer ch 2 -strobe Made in Italy by SGM Electronic Printed in July, 1998 • Rel. 1.00...
- Page 4 Main features SGM’s new Flasher DMX 1.5 strobe unit is another result of the firm’s lengthy experience in manufac- turing this type of fixture. The quality and design philosophy are those which all SGM products have had in common for years and the sophisticated electronics used combined with ground-breaking performance earn it a rightful place at among the world’s top products.
- Page 5 Trouble-free horizontal, vertical or tilted positioning is possible, provided sufficient space is left round the unit for air circulation. Flasher DMX 1.5 maintenance Access to internal components The Flasher has a system for access to the fixture’s internal components, which prevents accidental opening.
- Page 6 above all on the surroundings in which the unit is used: damp, smoky or dusty surroundings in particu- lar favour a greater build-up of dirt on the unit’s glass. Clean using a soft cloth and normal glass cleaning products or methylated spirits, always being certain to dry the parts.
- Page 7 Connecting the Flashers The fixture has DMX 512 input/output. For connection, always use quality balanced microphone cables DMX socket pin out such as RF 60/12 2x0.25mm or similar to avoid faulty fixture input output operation. To reduce interference, it may be necessary to fit the last fixture in the DMX chain with a system terminator, made using a 120Ohm 1/4W resistor between pins 2 and 3 on the DMX con- pin 1...
- Page 8 Via Pio La Torre, 1 • 61010 TAVULLIA (PS) • ITALY • Tel. +39 0721476477 • Fax +39 0721476170 www.sgm.it • info@sgm.it...
