Kunzle & Tasin Bona Belt Quick Start Manual

Phone 1300 882 806
Bona Belt
The Bona Belt sanding machine makes big jobs seem small.
makes the machine simple to manoeuvre and easy to transport. It can be disassembled
and reassembled quickly and easily. The Bona Belt has a very efficient dust pick up,
leaving a cleaner floor. For optimal dust reduction, the Bona Belt is compatible with the
Bona DCS 70 (Bona Dust Containment System).
Suitable for sanding all kinds of timber and parquet floors, the Bona Belt is a machine for
all occasions.
•
Unique construction gives a choice of a 250 mm or 200 mm drum
•
Ergonomically designed handle allows fingertip control to raise and lower the drum.
•
Large front and side covers make the drum and tension roller easy to reach.
•
Very efficient dust pick up
•
A compact design gives excellent manoeuvrability
•
Easy to transport due to the quick breakdown of the machine
Technical data
250 mm – Standard / 200 mm - Option
Drum width:
250 x 750 mm – Standard
Sanding belt size:
Motor power: 1-phase 2.2 KW with Easy start
Total weight: 81 KG: 74 KG + 7KG weight
Drum revolutions: 1800 rpm
Dust discharge: < 2 mg / m³ air (Using the Bona Dust bag)
For further more detailed technical data please see the machine manual.
Directions for use
When using the Bona Belt for the first time, read the machine manual carefully and
follow the instructions to set the machine up.
Check that the sanding drum is raised and connect the cable to the power socket. For
your own safety - always use an earth leakage circuit breaker.
Start the machine and let it run for a few seconds so that the dust bag is filled with air
and the motor reaches full speed. You will note that the motor sound changes during
this time as the Easy start system operates to prevent high load on the motor during the
start-up process.
At this point, check that the sanding belt is adjusted properly. If required use the fine
adjustment screw on the housing above the drum to centre the sanding belt. Close the
front and side access panels firmly. Adjust the drum pressure as required using the
adjustment handle at the rear of the machine. In general terms the coarser the abrasive
being used the higher the drum pressure required.
Vacuum the floor properly between each sanding operation so that it is clean before
continuing. Whilst the dust collection system on sanding machines is efficient, the
possibility of dust or abrasive particles remaining on the floor exists. The use of sanding
machines on a poorly cleaned floor can push these particles into the surface of the
timber causing issues with discolouration.
If there is any damage to the floor that needs to be repaired or nail holes are to be filled,
these operations should be completed during the sanding process using Bona Mix&Fill
or a proprietary filler. It is not recommended to apply filler after the application of a Bona
primer.
Australian datasheet only – June 2014
The compact design
/
200 x 750 mm - Option
