CATEYE STRADA CADENCE
Quick Start Manual
Install the speed sensor
Install the wheel magnet
Install the cadence sensor
Install the cadence magnet
Adjust the positions of the
sensor and magnet
Adjust the clearance between
the sensor and magnet

Route the cable

Fixing the sensor and magnet
(Installation is completed)
Route the cable
Fix the wire to the frame with nylon ties where ap-
plicable, and route it to the handle while winding
around the brake cable. Cut off any excess nylon tie
using a nipper.
Caution:
Return
Return to Contents
How to install the sensor
Adjust this section so that the wire is
not stretched when you turn the handle.
Nylon ties
Next
