CATEYE STRADA CADENCE
Quick Start Manual
Install the speed sensor
Install the wheel magnet
Install the cadence sensor
Install the cadence magnet
Adjust the positions of the
sensor and magnet
Adjust the clearance between
the sensor and magnet
Route the cable
Fixing the sensor and magnet
(Installation is completed)
Left Chain Stay (Outside)
3 mm
Cadence sensor
Return
Adjust the clearance between the sen-
sor and magnet
Adjust the clearances between the speed sensor and
wheel magnet and the cadence sensor and cadence
magnet, so that both of them are within 3 mm.
*
When the clearance between the cadence sensor
and cadence magnet is more than 3 mm, install the
cadence sensor with sensor rubber pads in layers.
Left Chain Stay (Inside)
Wheel magnet
Cadence magnet
Return to Contents
How to install the sensor
3 mm
Speed sensor
Next
