CATEYE STRADA CADENCE
Quick Start Manual
Install the speed sensor
Install the wheel magnet
Install the cadence sensor
Install the cadence magnet
Adjust the positions of the
sensor and magnet
Adjust the clearance between
the sensor and magnet
Route the cable
Fixing the sensor and magnet
(Installation is completed)
Install the cadence magnet
Temporarily secure the cadence magnet to the in-
side of the left crank with nylon ties.
Tighten the cadence magnet to such an extent that
it can be moved.
Return
Return to Contents
How to install the sensor
Left crank (Inside)
Nylon ties
Cadence sensor
To the SENSOR LINE
Cadence magnet
Next
