Adjust the positions of the sensor and magnet
Adjust the positions so that the wheel magnet pass-
es through the SENSOR LINE of the speed sen-
sor, and the cadence magnet passes through the
SENSOR LINE of the cadence sensor.
Return
SENSOR LINE
(Cadence sensor)
Cadence
magnet
Return to Contents
How to install the sensor
Wheel magnet
SENSOR LINE
(Speed sensor)
