CATEYE STRADA CADENCE
Quick Start Manual
Install the speed sensor
Install the wheel magnet
Install the cadence sensor
Install the cadence magnet
Adjust the positions of the
sensor and magnet
Adjust the clearance between
the sensor and magnet
Route the cable
Fixing the sensor and magnet
(Installation is completed)
Install the wheel magnet
Temporarily secure the wheel magnet to the left
spoke of the rear wheel.
Tighten the wheel magnet to such an extent that it
can be moved.
Return
Return to Contents
How to install the sensor
Rear wheel spoke
Wheel magnet
Speed sensor
To the SENSOR LINE
