Retro Pedestal - TV Unit
Assembly Instructions -
Dimensions
Width - 119.5cm
Depth - 39.5cm
Height - 35.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
332/5476
MADE IN
BRITAIN
Issue 1 - 01/12/14
Advertisement
Related Manuals for Argos 332/5476
Summary of Contents for Argos 332/5476
- Page 1 Retro Pedestal - TV Unit Assembly Instructions - 332/5476 Please keep for future reference Dimensions Width - 119.5cm Depth - 39.5cm MADE IN Height - 35.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 20kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Left Divider (DF1089) (DF1090) (DF1088) (235 x 390mm) (235 x 390mm) (1194 x 392mm) Right Side...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the drawer front Screw 2 metal dowels into the drawer front Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 7 Prepare the left divider Tap 2 wooden dowels into the left divider 10mm Note: Wooden dowels must not stick out from the edge by more than 10mm or they may Finished damage other panels. front edge Place a runner on the left divider...
- Page 8 Assembly Instructions Step 9 Fit the left divider to the top Push the left divider onto the top Use a screwdriver to tighten the 2 large locking nuts fitted to the left divider Finished front edge Note: Turn the large locking nuts as far as Finished...
- Page 9 Assembly Instructions Step 11 Fit the left side Push the left side onto the top Use a screwdriver to tighten the 2 large locking nuts fitted to the left side Finished front edge Step 12 Prepare the right side Tap 2 wooden dowels into the right side Insert 2 large locking nuts...
- Page 10 Assembly Instructions Step 14 Prepare the right Finished divider front edge Tap 2 wooden dowels into the right divider Insert 2 large locking nuts into the right divider Step 15 Fit the right divider Push the right divider onto the top Use a screwdriver to tighten the 2 large locking nuts...
- Page 11 Assembly Instructions Step 17 Fit the feet Fit the 4 feet to the base using screws and tighten them using the allen key Note: You may find it easier to turn the foot as the screw is held with the allen key. Step 18 Fit the rail Attach the rail...
- Page 12 Assembly Instructions Step 19 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back The gap at this end is Square up the unit by for cable management making sure that measurement x to x...
- Page 13 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 16 ALR3119...
