ASSEMBLY INSTRUCTIONS
We have designed our furniture with you , the customer in mind . Our clear , easy to follow ,
step by step instructions will guide you through the project from start to finish .
Feel confident that this will be a fun and rewarding project . The final product will be a quality
piece of furniture that will go together smoothly and give years of enjoyment .
Please do not return to the store
STOP
Broken or missing parts?
Need help with assembly?
Our Illinois based customer service team is ready to help with any problems or questions you may have.
Please give us a call (Toll Free) at 1-800-468-6447, or email us at parts@convenience-concepts.com.
Normal hours of Operation: M-F* 8am-4pm CST.
*Excludes Holidays
This product's warranty is only valid through authorized dealers.
DIAMOND 1 DRAWER
CONSOLE TABLE
303299
version:2019.8.5
Advertisement
Related Manuals for convenience concepts DIAMOND 303299
Summary of Contents for convenience concepts DIAMOND 303299
- Page 1 version:2019.8.5 DIAMOND 1 DRAWER CONSOLE TABLE 303299 ASSEMBLY INSTRUCTIONS We have designed our furniture with you , the customer in mind . Our clear , easy to follow , step by step instructions will guide you through the project from start to finish . Feel confident that this will be a fun and rewarding project .
-
Page 2: Hardware List
Hardware List Small Screw (4pc) Cam Lock (23pc) Screw (7pc) Cam Bolt ( 23pcs ) Wood Dowel( 4pcs ) 3.5*12 Anti-Tip Bracket Skinny Wooden Dowel Left Glide (1pc) Right Glide (1pc) Anchor (2pc) ( 2pcs ) ( 4pcs ) Handle Screw Small Screw (2pc) LOCK Nut( 8pcs ) Handle (2pc) -
Page 3: Panel List
Panel List Top panel Right Side Panel Back support Bar Support Bar Left Side Panel Middle Shelf Bottom Shelf Bottom Support Bar Drawer Right Side Panel Drawer Back Panel Bottom Support Bar Drawer Bottom Panel Drawer Front Drawer Left Side Panel Drawer Support Bar *Please count and verify all parts before assembly .* Page 3 of 9... - Page 4 Assembling the unit with camlocks and wood dowels. Arrow must face hole Gently screw cambolt Lightly glue one end of Lightly glue wood dowel and Screw the camlock into the threaded anchor. the wood dowel and tap connect to second panel by firmly into locked halfway into hole.
- Page 5 Step 2 *Assemble unit on carpet or flat surface. 1.Attach Glider (F) to left side panel using screw (E) . 2.Attach Glider (G) to right side panel using screw (E) . Step 3 1.Attach bottom support bar to shelf using Camlocks (B) by gently tightening camlocks .
- Page 6 Step 4 1.Connect back support bar and support bar to left side panel using camlocks(B) 2.Connect shelves using bolts (L) and locknuts (M) as shown. Step 5 1.Connect right side panel to unit using camlocks (B) ,bolts (L) and lock nuts (M) . Page 6 of 9...
- Page 7 Step 6 1.Attach top panel to back support bar and side panels & using camlocks(B). Step 7 1.Attach drawer side panels & and drawer bottom support bar to drawer back panel using screws (D). 2.Insert drawer bottom panel into grooves of drawer assembly. 3.Connect drawer front to assembly by using comlocks (B) 4.Attach handles (N) to drawer front...
- Page 8 Step 8 1.Carefully insert drawer into unit. 2.If desired ,place Stickers (I) over screw holes. Step 9 1.Attach anti-tip brackets (I) to left panel & right panel using small screw (O). 2.Place unit againts wall and mark bracket holes. Page 8 of 9...
- Page 9 Step 10 1.Drill holes in wall slightly smaller than anchor (H) and gently tap anchors into holes. 2.Fasten unit to wall using screw (D) through brackets (I). 3.Enjoy. Page 9 of 9...
