IP Cam Surveillance

With the Simple Surveillance Server,
you can connect an IP cam to the
N199 to capture images. The Simple
Surveillance Server also supports
scheduling, which means that you
can configure the N199 to perform
surveillance at any time.
From the Status menu, choose the
IP Cam Surveillance item, and the
IP Cam Surveillance Information
screen appears. The IP Cam screen provides information and allows you to
configure the Simple Surveillance Server.
IP Camera
Item
Location
URL
Interval
Folder
Action
Apply
Cancel
You can also designate a schedule for the Simple Surveillance Server using the
Schedule Configuration window:
Schedule Configuration
Item
Schedule Start
Frequency
Start Time
End Time
Apply
Cancel

IP Cam Configuration

Setting up an IP Cam for use with the N199 is easy. In this example, we'll setup a
Vivotek PT7237 IP cam for use with the N199. Configuring a different IP cam will
be slightly different depending on the model you are using, but this guide will
outline the basics.
Follow the instructions included with your IP cam for installation. Once your IP
cam is properly installed, follow the steps below to configure your N199.

Step 1: Connect the IP Cam to the N199

The first step is to connect your IP cam to the N199. To do this, login to the
N199's Web Admin Interface and select IP Cam Surveillance from the menu.
The IP Cam Surveillance window will appear. Here, we will connect your
installed IP Cam to the N199.
Description
Specify the location where the IP Cam located.
Input the URL address to capture the image.
Designates the interval for each captured frame.
Input where the images will reside.
Click ADD to add the task, Delete to remove task.
Click Apply to save changes.
Click Cancel to abandon changes.
Description
Checked on enable to activate image capture.
Frequency of the schedule. Select from Daily and Weekly
Scheduled time for image capture to begin.
Scheduled time for image capture to finish.
Click Apply to save changes.
Click Cancel to abandon changes.
57
