Solar Cell I-V Test System (Manual)
6.
Specifications
The Solar Cell I-V Test System (Manual) specifications are shown in Table 6.1.
Table 6.1. Ossila Solar Cell I-V Test System (Manual) specifications.
Voltage range
Voltage accuracy
Voltage resolution
Current range
Current accuracy
Current resolution
Substrate Size
Substrate Compatibility -
T2003A
Substrate Compatibility -
T2003B
Substrate Compatibility -
T2003C
Substrate Compatibility -
T2003E
Overall Dimensions
Ossila.com
±10 mV to ±10 V
±10 mV offset
170 μV
±10 nA to ±200 mA (5 ranges)
±10 nA (at 20 μA range)
0.1 nA (at 20 μA range)
20 mm x 15 mm
25 mm x 25 mm
S101
S211
S171
S2006
Source Measure Unit: Width: 125 mm; Height: 55 mm; Depth: 185 mm
Test Board: Width: 105 mm; Height: 40 mm; Depth: 125 mm
9
User Manual
Ossila Limited © 2022
