Solar Cell I-V Test System (Automated)
6.
Specifications
The Solar Cell I-V Test System (Automated) specifications are shown in Table 6.1.
Table 6.1. Ossila Solar Cell I-V Test System (Automated) specifications.
Voltage range
Current range
Substrate Size
Substrate Compatibility -
T2003A
Substrate Compatibility -
T2003B
Substrate Compatibility -
T2003C
Substrate Compatibility -
T2003E
Overall Dimensions
Ossila.com
±333 µV to ±10 V
±10 nA to ±200 mA
20 mm x 15 mm
25 mm x 25 mm
S101
S211
S171
S2006
Width: 150 mm
Height: 55 mm
Depth: 300 mm
9
User Manual
Ossila Limited © 2022
