  • Page 1 L8542943 11/2011 rev 0 CP.BISON OM UNIONE NAZIONALE COSTRUTTORI AUTOMATISMI PER CANCELLI, PORTE SERRANDE ED AFFINI...
  • Page 2 J1 DAS Close DAS 8K2 J1 DAS Open DAS N.C. ENCODER 230V: T0,315 115V: T0,5 230V: F5A 230V: T1A 115V: F10A 115V: T1A...
  • Page 3 SCA 24Vac 2ch:ON 2ch:Off 2ch:Off Service 3W max Radio Light serl:Off serl:Off serl:on 230V Relè 24Vac 24Vac COM NC 24Vac 24Vac COM NC 24Vac tst1:On tst2:On MINV:On OPEN MINV:Off OPEN...

  • Page 4: Technical Data

    EC declaration of confirmity Manufacturer: Automatismi Benincà SpA. Address: Via Capitello, 45 - 36066 Sandrigo (VI) - Italia Herewith declares that: control unit CP.BISON OM. complies with the following relevant provisions: EMC guidelines: 89/336/CCE, 93/68/CEE Low voltage guidelines: 73/23/CEE, 93/68/CEE Benincà...

  • Page 5: Input/Output Functions

    CP.BISON OM CONTROL UNIT INPUT/OUTPUT FUNCTIONS Terminal No. Function Description Power supply Input, 230Vac 50Hz (1-Phase/2-Neutral) Ground connection. Use the connector preset on the fitting plate of the control unit. Earthing is COMPULSORY, through this connection also the metal structure of motoriza- tion are grounded.
  • Page 6 closing cycles. When the procedure is completed OK will be displayed. This procedure can be followed from any position of the gate/door leaf and can be stopped at any moment by pressing keys <+> and <-> at the same time, or through the activation of STOP/PHO/PHA/DAS/PP/PED inputs. If the procedure is not successful, the wording ERR appears.
  • Page 7 LOGICS (LOG) MENU FUNCTION DEFAULT MEMO The automatic closure is enabled or disabled On: enabled automatic closure (ON) Off: disabled automatic closure The multi-flat function is enabled or disabled. On: enabled multi-flat function. The P.P. (Step-by-step) impulse or the impulse of the (OFF) transmitter have no effect in the opening phase.
  • Page 8 The operating mode of the PHOT C input is selected. On: PHOT C input is activated in both opening and closing phases. In the opening phase: the contact opening causes the motor stop. When the photocell is released, the motor restarts in the opening phase. PHcl In closing phase: the contact opening causes the motor stop.
  • Page 9 AUTOSET (AUTO) The learning of the system stroke and the operating torque adjustment are carried out. See paragraph SELF-LEARNING PASSWORD (CODE) It allows to type in an access protection code to the programming of the control unit. A four-character alphanumeric code can be typed in by using the numbers from 0 to 9 and the letters A-B-C-D-E-F. The default value is 0000 (four zeros) and shows the absence of a protection code.

  • Page 10: Waste Disposal

    DIAGNOSTICS In the event of malfunctions, by pressing key + or - the status of all inputs (limit switches, control and safety) can be displayed. One segment of the display is linked to each input. In the event of failure it switches on according to the following scheme. P.P.
