- Page 1 PERIMETER LIMITER OSHA 1926.502 OSHA 1910.140 Counterweight Fall Arrest System USER INSTRUCTIONS 5902381 R 2100090 © 3M 2020...
- Page 4 45° 45° 45°...
- Page 7 ≤ 310 lbs. ≤ 310 lbs. (140 kg) (140 kg) OSHA ≤ 1,350 lb. (6 kN) MAF & 1926.502 / 1910.140 ≤ 900 lb. (4 kN) AAF 20XX XX / XX 20__ 20__ 20__ 20__ 20__ ≤ 24’ (7.31m) 20__ 20__ 20__ 20__...
-
Page 8: Safety Information
Ensure there is adequate fall clearance when working at height. Never modify or alter your fall protection equipment. Only 3M or parties authorized in writing by 3M may make repairs to the equipment. Prior to use of fall protection equipment, ensure a rescue plan is in place which allows for prompt rescue if a fall incident occurs. -
Page 9: Product Description
Inspection and Maintenance Log (Table 2) at the back of this manual. PRODUCT DESCRIPTION: Figure 1 illustrates the assembled 3M™ DBI-SALA™ Perimeter Limiter System. It is used an an anchorage for a Personal Fall Arrest System (PFAS) for a person working on form work, flat roofs, or similar structures. -
Page 10: Product Application
Contact 3M if you have any questions about compatibility. Connectors (hooks, carabiners, and D-rings) must be capable of supporting at least 5,000 lbs. (22.2 kN). Connectors must be compatible with the anchorage or other system components. - Page 11 3M connectors (snap hooks and carabiners) are designed to be used only as specified in each product’s user’s instructions. See Figure 7 for examples of inappropriate connections. Do not connect snap hooks and carabiners: To a D-ring to which another connector is attached.
-
Page 12: Installation
DEFECTS: If inspection reveals an unsafe or defective condition, remove the Perimeter Limiter from service immediately and contact 3M regarding replacement or repair. Do not attempt to repair the Fall Arrest System. Authorized Repairs Only: Only 3M or parties authorized in writing my make repairs to this equipment. - Page 13 Ensure parts are thoroughly rinsed with clean water. SERVICE: Only 3M or parties authorized in writing by 3M may make repairs to this equipment. If the Perimeter Limiter has been subject to fall force or inspection reveals an unsafe or defective conditions, remove the system from service and contact 3M regarding replacement or repair.
- Page 14 Table 2 – Inspection and Maintenance Log Inspection Date: Inspected By: Competent Components: Inspection: User Person (See Section 1 for Inspection Frequency) Perimeter Limiter Inspect the Perimeter Limiter for damage: Look for cracks, dents, or deformities. (Figure 2) Inspect the entire unit for corrosion. Labels (Figure 11) Verify that all labels are securely attached and are legible (see ‘Labels’) PFAS and Other...
- Page 16 LIMITED REMEDY: Upon written notice to 3M, 3M will repair or replace any product determined by 3M to have a factory defect in workmanship or materials. 3M reserves the right to require product be returned to its facility for evaluation of warranty claims. This warranty does not cover product damage due to wear, abuse, misuse, damage in transit, failure to maintain the product or other damage beyond 3M’s control.
