INSTRUCTION MANUAL
VC-700WDR
COLOR DOME CAMERAS
About this manual
Before installing and using the camera, please read this manual carefully.
Be sure to keep it handy for later reference.
This installation should be made by a qualified service person and should conform to the
National Electric Code, ANSI/NFPA 70 and all local codes.
Installers should use appropriate hardware mounting materials.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VC-700WDR and is the answer not in the manual?

Questions and answers

Related Manuals for Vicon VC-700WDR

Summary of Contents for Vicon VC-700WDR

  • Page 1 INSTRUCTION MANUAL VC-700WDR COLOR DOME CAMERAS About this manual Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for later reference. This installation should be made by a qualified service person and should conform to the National Electric Code, ANSI/NFPA 70 and all local codes.
  • Page 2 Dimensions : inch (mm) Surface-Mount configuration In-Ceiling configuration...
  • Page 3 PRECAUTIONS ■ Do not open or modify Do not open the case except during maintenance and installation, as it may be dangerous and cause damages. ■ Do not put objects inside the unit Make sure that no metal objects or flammable substances get inside the camera.

  • Page 4: Troubleshooting

    TROUBLESHOOTING Before sending the camera out for repair, check the items below. If the problem persists after checking these items, contact your service center. ■ If no image appears ▪ Is the coaxial cable attached securely? ▪ Are the power and voltage normal? ▪...

  • Page 5: Lens Adjustment

    LENS ADJUSTMENT SCREW (2X) TILT ZOOM 90˚ FOCUS 1. Adjust the panning (360˚) and tilt (90˚) position. 2. Set the zoom position by using Zoom Lever Screw. 3. Set the focus by using Focus Lever Screw. 4. Loosen set screws (using small M1.0 Hex L-wrench provided) to adjust roll (turns camera position top/bottom).

  • Page 6: Specification

    SPECIFICATION General Spec NTSC 1/3" PIXIM CMOS progressive CCD Type 742(H) X 552 (V) Total num ber of pixels 0.06fc(0.6Lux) F1.2, 30IRE at COLOR Min illum ination 0.008fc(0.08Lux) F1.2, 30IRE at BW(TDN) 1.0Vp-p/75 ohm Composite Video Output 540 TV Lines Resolution 48dB or more(AGC off) S/N Ratio...
  • Page 7 CONNECTIONS 12VDC-24VAC RED (+) BLACK (-) VIDEO 11.8in (300mm 12VDC-24VAC RED (+) BLACK (-) VIDEO...
  • Page 8 CAUTION The use of a UL Listed Class 2 power supply is required to ensure compliance with electrical safety standards. Check for polarity when using a 12VDC power supply. Cable for connection to portable monitor, provided. When using a portable monitor, terminate at 75ohms (at last device).
  • Page 9 Surface-Mount Base In-Ceiling Base...

  • Page 10: Camera Settings

    CAMERA SETTINGS ■ CAMERA SETTINGS...
  • Page 11 WDR Camera Adjustments The adjustments are done via an OSD menu using a joystick on the WDR board. The camera must be connected to a portable (local) monitor to use the menu system. Use the cable included in the accessory kit. There is a 2-position DIP switch on the camera board to set NTSC or PAL. This is factory set.
  • Page 12 The Wide Dynamic Range (WDR) level can be adjusted from 20 to -20 (default is -2). The Exposure Level can be set for from 18 to -18 (default is 0). WB Control The White Balance can be controlled by: ATW (default): The camera automatically controls the white balance in any environment AWB: One time automatic adjustment for a specific environment.
  • Page 13 Day/Night The user can select how the day/night function is set for changing from color to black-and-white: AUTO (default): Color  BW Level 20 to 35 (default is 32); BW  Color level 0 to 10 (default is 5). Color Exit Menu When selecting Exit, the user can: EXIT NO CHANGES: Exits the menu system without making any changes...

  • Page 14: Installation

    INSTALLATION 2.46(R62.5) 2.30(R58.5) 4-0.17(Θ4.3) 2.46(R62.5) 2.30(R58.5) 360˙...
  • Page 15 This model can be either mounted to a surface (like a ceiling or wall) or installed into the ceiling, with or without an electrical box. Use the large (Torx T20) L-Wrench to loosen the 4 screws (B) securing the dome assembly. For surface-mount installations, align the mounting base (D) with the mounting surface;...
  • Page 16 Vicon Industries Inc. Corporate Headquarters European Headquarters 89 Arkay Drive Brunel Way Hauppauge, New York 11788 Fareham, PO15 5TX United Kingdom 631-952-CCTV (2288) 800-645-9116 +44(0) 1489 566300 Fax: 631-951-CCTV (2288) Fax: +44(0) 1489 566322 Far East Office Germany Unit 5, 17/F, Metropole Square...
