SMART-AVI HDC-IR Quick Start Manual

TECHNICAL SPECIFICATIONS
IR-EYE
IR Frequency Range 30 KHz to 80 KHz
Capture Distance Up to 25'
Cable Connector 3.5 mm stereo jack
IR Signal Indicator Green LED
IR-EYE
IR Frequency Range 30 KHz to 80 KHz
Capture Distance Up to 10'
Cable Connector 3.5 mm stereo jack
IR Signal Indicator Red LED
OTHER
Power 12VDC 2A
Cable Link CAT5 568A or 568B
Dimensions 2.5" W x 2.5" D x 1.0" H
Weight .25 lb
Operating Temp. 0°C ~ 40°C / 32°F ~ 104°F
Storage Temp. -20°C ~ 70°C / -4°F ~ 158°F
Relative Humidity Up to 95%
WHAT'S IN THE BOX
PART NO. QTY DESCRIPTION
HDC-IR 2 IR CAT5 Point to Point
SM-LED 1 IR Emitter
SM-EYE 1 IR Eye (Optional)
PS12VDC2A 2 Power supply 12VDC2A
1 Quick Start Guide
NOTICE
The information contained in this document
is subject to change without notice. iPGARD
makes no warranty of any kind with regard
to this material, including but not limited to,
implied warranties of merchantability and
fitness for a particular purpose. iPGARD
will not be liable for errors contained
herein, or for incidental or consequential
damages in connection with the furnishing,
performance, or use of this material. No
part of this document may be photocopied,
reproduced, or translated into another
language without the prior written consent
from iPGARD, Inc.
20170518
DESIGNED
AND MADE
IN THE USA
Toll Free: (888)-994-7427
Phone: (702) 800-0005
Fax: (702)-441-5590
WWW.iPGARD.COM
HDC-IR
IR CAT5 Point to Point Extender
USES A SINGLE CAT5
TO BROADCAST IR
UP TO 1000FT AWAY(333M
Quick Start Guide
