- Page 1 User Manual Elo Touch Solutions KIT-NFC-LF/HF-EDGE CONNECT UM600632 Version: B Copyright © 2021 Elo Touch Solutions, Inc. All Rights Reserved. User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 1 of 20...
- Page 2 Solutions, Inc. Disclaimer The information in this document is subject to change without notice. Elo Touch Solutions, Inc. and its Affiliates (collectively "Elo") makes no representations or warranties with respect to the contents herein, and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose. Elo reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Elo to notify any person of such revisions or changes.
-
Page 3: Table Of Contents
Chapter 2 Installation Guide ......................5 Chapter 3 Getting Started Guide ....................... 8 Chapter 4 Technical Support ......................15 Chapter 5 Safety and Regulatory Information ................16 Chapter 6 Warranty Information ...................... 19 User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 3 of 20... -
Page 4: Chapter 1 Introduction
119.6mm x 68.5mm x 29.1mm power supply 5VDC ± 5% The host interface USB2.0 Operating temperature 10°C-40°C (50°F-104°F) Working humidity 20% - 80% Storage temperature 0°C-50°C (32°F-122°F) Store humidity 10% - 90% buzzer backing User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 4 of 20... -
Page 5: Chapter 2 Installation Guide
Note: The following images may vary for different products. Step 1: Select location to mount the RFID device. Step 2: Remove the selected peripheral interface cover from the side of the main device. User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 5 of 20... - Page 6 (Note: Do not adjust the angle of the NFC reader without screws, as this may cause damage.) Step 5: Attach the screws in the accessory bag to protect the mera and adjust the angle as needed. User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 6 of 20...
- Page 7 OMNIKEY 5x27 EEM Driver Android platform : • Download the corresponding installation APK by visiting the link website below. http://www.hidglobal.com/drivers. Other platforms: • Please visit and search for information via the link below. http://www.hidglobal.com User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 7 of 20...
-
Page 8: Chapter 3 Getting Started Guide
The tab contains basic information about the connected smart card reader. All information in this tab is fixed and cannot be changed. Displays a product image so that you know which device you are using. User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 8 of 20... - Page 9 Card Diagnostic Options The Card Diagnostics option contains information about the current smart card, such as ATR, PACS bits, and card descriptions. User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 9 of 20...
- Page 10 USB-connected hosts to access TCP/IP services, such as built-in web servers. All CCID commands can be pushed to the device via HTTP via the EEM interface. The EEM interface is turned on by default. User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 10 of 20...
- Page 11 • Click RESTORE to restore the RFID device to factory settings. APPLY and RESTORE settings require a USB reconnection, which causes the reader to disappear briefly from the list of available readers. User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 11 of 20...
- Page 12 WBO files to get the latest firmware from the HID official link below. https://www.hidglobal.com/developer-center. Note: Access to the HID Developer Center requires a license key account, which can be obtained by placing an order. User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 12 of 20...
- Page 13 After loading the WBO file, you can compare the firmware version currently installed on the device with the version in the file and decide whether to proceed with the upgrade process. Once you have confirmed the firmware upgrade, click the UPLOAD option and wait for the upgrade. User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 13 of 20...
- Page 14 For more detailed settings files for your device, please visit the official HID website www.hidglobal.com search for the following files: • OMNIKEY 5x27CK Software Developer Guide • OMNIKEY® 5X27CK KEYBOARD WEDGE CONFIGURATION AND CUSTOM REPORT USER GUIDE User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 14 of 20...
-
Page 15: Chapter 4 Technical Support
Please visit the website service technical support For technical specifications for this www.elotouch.com/go/websupport www.elotouch.com/go/contactsuppo device, visit the website www.elotouch.com/products For global technical support phone numbers, see the last page of this user manual. User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 15 of 20... -
Page 16: Chapter 5 Safety And Regulatory Information
1. In order to meet emission and immunization requirements, users must comply with the following regulations: a. Connect the digital device to any computer using only provided I/O cable. b. To ensure compliance, use only the manufacturer-approved power cord provided. User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 16 of 20... - Page 17 • UL, FCC (US) – Class B • cUL, IC (Canada) • CB (International Safety) • SRRC(China) • CE (Europe) – Class B • VCCI (Japan) • RCM (Australia) • China RoHS User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 17 of 20...
- Page 18 In accordance with Chinese law, the Measures for the Regulation of the Restricted Use of Hazardous Substances in Electrical and Electronic Products, the following sections list the names and contents of hazardous substances that may be contained in the product. User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 18 of 20...
-
Page 19: Chapter 6 Warranty Information
Chapter 6 Warranty Information For warranty information, please visit http://support.elotouch.com/warranty/ User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 19 of 20... - Page 20 Product information The instructions Event preview Press releases Software-driven For more information on the product range of Elo touch solutions, visit our website www.elotouch.com or call your nearest office. North America Tel: 1 408 597 8000 Fax: 1 408 597 8001 andlosales.na@elotouch.com...
