- Page 1 USER MANUAL Elo Touch Solutions 1537L Touchmonitors SW600877 Rev D...
- Page 2 Elo Touch Solutions, Inc. Disclaimer The information in this document is subject to change without notice. Elo Touch Solutions, Inc. and its Afffiliates (collectively "Elo") makes no representations or warranties with respect to the contents herein, and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose.
-
Page 3: Table Of Contents
Chapter 3: Operation ................11 Chapter 4: Technical Support ..............19 Chapter 5: Safety & Maintenance ............21 Chapter 6: Regulatory Information ............23 Chapter 7: Warranty Information ............28 User Manual: 1537L SW600877 Rev D, Page 3 of 29... -
Page 4: Chapter 1: Introduction
Chapter 1: Introduction Product Description Your new touchmonitor combines the reliable performance of Elo Touch Solutions touch products with the latest developments in touchscreen technology and display design. This combination of features ensures a product with stable, drift-free operation, consistent reliability and durability, backed by a 3-year standard warranty. -
Page 5: Chapter 2: Installation
Serial cable Mounting brackets Connector Panel & Interfaces Note: Before connecting the cables to your touchmonitor and computer, be sure that the computer and touchmonitor are turned off. User Manual: 1537L SW600877 Rev D, Page 5 of 29... - Page 6 5. Connect one end of OSD remote control key (optional) to the monitor. Installing the Touch Technology Software Drivers Some software installation is required for your touchmonitor to work with your computer. The drivers are available on the Elo Touch Solutions website. Visit www.elotouch.com for: ...
- Page 7 Select the applicable driver from the Elo Touch Solutions website and download: For Windows 7 installations, double-click on EloSetup Installer User Manual: 1537L SW600877 Rev D, Page 7 of 29...
- Page 8 To complete setup, reboot system by clicking on “Reboot Now” button. Click on “One More Minute” if more time is needed with increments of 1 minute. Note: System will automatically reboot when “Time left” counter reaches “0”. User Manual: 1537L SW600877 Rev D, Page 8 of 29...
- Page 9 For Windows XP installations, double-click on the icon from the desktop Click on “Unzip” button to unzip files. User Manual: 1537L SW600877 Rev D, Page 9 of 29...
- Page 10 Select one or more of the drivers to install. Click on “Next” After accepting the end-user license agreement, the drivers will finish installing. Reboot your computer after the installation is complete. User Manual: 1537L SW600877 Rev D, Page 10 of 29...
-
Page 11: Chapter 3: Operation
Four OSD buttons are provided on the rear of the monitor to adjust various display parameters. The same buttons are provided on an optional OSD Control Box which can plug into the RJ-45 connector on the touchmonitor connector panel. User Manual: 1537L SW600877 Rev D, Page 11 of 29... - Page 12 The touchscreen may need recalibration when switching between Aspect Ratio options. Adjusts sharpness of the displayed images. Sharpness Default: no sharpness adjustment Only applicable at non-native input video resolutions User Manual: 1537L SW600877 Rev D, Page 12 of 29...
- Page 13 Press and hold the “Menu” and “ ” buttons for two seconds to enable/disable the Power Locking feature. When the Power Locking is enabled, pressing the power switch will have no effect on the system. User Manual: 1537L SW600877 Rev D, Page 13 of 29...
-
Page 14: Preset Modes
VESA 1024 x 768 60 Hz 48.36 SUN 1024 x 768 65 Hz 52.45 70.49 VESA 1024 x 768 70 Hz 56.48 VESA 1024 x 768 75 Hz 60.02 78.75 User Manual: 1537L SW600877 Rev D, Page 14 of 29... -
Page 15: Power Management System
The IntelliTouch Plus driver will only support multiple monitor if they are all using the IntelliTouch Plus touchscreen technology. To use multiple IntelliTouch Plus monitors, plug in monitors to calibrate, double-click on the EloConfig desktop shortcut to run Elo Touchscreen Configuration screen. User Manual: 1537L SW600877 Rev D, Page 15 of 29... - Page 16 Click on “Calibrate Touch Screens…” to calibrate multiple monitors. Tap monitor screen to identify monitor’s identity as shown below. User Manual: 1537L SW600877 Rev D, Page 16 of 29...
- Page 17 Identity of the monitor will display. Click on “OK” to proceed to calibration. Calibrate touch as targets appear on corners of the screen. Follow instructions on screen. User Manual: 1537L SW600877 Rev D, Page 17 of 29...
- Page 18 The IntelliTouch Plus touch technology enables several gestures that support single and multiple touches. Refer to the Microsoft Website http://msdn.microsoft.com/en- us/library/dd940543 on the various gestures that are supported in Windows 7. User Manual: 1537L SW600877 Rev D, Page 18 of 29...
-
Page 19: Chapter 4: Technical Support
If you are experiencing trouble with your touchmonitor, refer to the following suggestions. If the problem persists, please contact your local dealer or contact Elo Touch Solutions Customer Service. Worldwide technical support phone numbers are available on the last page of this use manual. - Page 20 Visit www.elotouch.com/products for technical specifications for this device Visit www.elotouch.com/go/websupport for online self-help. Visit www.elotouch.com/go/contactsupport for technical support. See this user manual’s last page for worldwide technical support phone numbers. User Manual: 1537L SW600877 Rev D, Page 20 of 29...
-
Page 21: Chapter 5: Safety & Maintenance
Never apply the cleaner directly to the touchscreen. Do not use alcohol (methyl, ethyl or isopropyl), thinner, benzene, or other abrasive cleaners. Ensure the environmental temperature and humidity are maintained within specification and do no block ventilation slots. Monitors are not designed for outdoors. User Manual: 1537L SW600877 Rev D, Page 21 of 29... - Page 22 Waste Electrical & Electronic Equipment Directive (WEEE) This product should not be disposed of with household waste. It should be deposited at a facility that enables recovery and recycling. User Manual: 1537L SW600877 Rev D, Page 22 of 29...
-
Page 23: Chapter 6: Regulatory Information
Directives and Standards: This equipment has been tested to the requirements for the CE Mark as required by EMC Directive 2004/108/EC as indicated in European Standard EN 55022 Class B and the Low Voltage Directive 2006/95/EC as indicated in European Standard EN User Manual: 1537L SW600877 Rev D, Page 23 of 29... - Page 24 (Removing or cutting the line cord ground may in crease RF emission levels and may also present a lethal shock hazard to the user.) If you need additional help, consult your dealer, manufacturer, or an experienced radio or television technician. User Manual: 1537L SW600877 Rev D, Page 24 of 29...
- Page 25 Lead(Pb) Mercury(Hg) Cadmium(Cd) Hexavalent Polybrominated Polybrominated Chromium Biphenyls (PBB) Diphenyl (Cr6+) Ethers (PBDE) Plastic Parts Metal Parts X Wire and Cable Assembly LCD Panel X Touch Screen Panel PCBA Software (CD, etc.) User Manual: 1537L SW600877 Rev D, Page 25 of 29...
- Page 26 The product should not be thrown away casually. V. Power Adapter Specifications Electrical Ratings: Input: 100 - 240VAC, 50/60Hz Output: 12VDC, minimum 4.16A, LPS (Power adapter needs to be UL approved) VI. Monitor Specifications Electrical Ratings: User Manual: 1537L SW600877 Rev D, Page 26 of 29...
- Page 27 Operating Conditions: Temperature: 0°C - 40°C Humidity: 20% to 80% (non-condensing) Altitude: 0 to 3,048m Storage Conditions: Temperature: -20°C - 60°C Humidity: 10% to 95% (non-condensing) Altitude: 0 to 12,192m User Manual: 1537L SW600877 Rev D, Page 27 of 29...
-
Page 28: Chapter 7: Warranty Information
Chapter 7: Warranty Information http://www.elotouch.com/Support/warranty.asp for more information. User Manual: 1537L SW600877 Rev D, Page 28 of 29... - Page 29 Press releases Software drivers Getting in Touch with us To find out more about the extensive range of Elo touch solutions, visit our website at www.elotouch.com, or simply call the office nearest you: North America Tel 800-ELO-TOUCH Europe...
