ASSEMBLY INTRUCTIONS FOR MAXI 16J3
NO
MODEL
DESCRIPTION
1
CONFIRMAT SCREWS
2
CAPS
3
SHELF PINS
4
BACKING NAILS
When attaching unit to wall put safety bracket in
middle of unit with 16 Pan head screw then
For plasterboard without a stud it is recommend-
X 2
NO
MODEL
QTY
20
5
20
6
8
7
75
TOP of UNIT
25mm Pan head screw into wall.
ed to use a plug with screw (not provided).
DESCRIPTION
BRACKETS
BRACKET UNIT SCREW
BRACKET WALL SCREW
QTY
1
1
1
Advertisement
Table of Contents
Related Manuals for Multistore MAXI 16J3
Summary of Contents for Multistore MAXI 16J3
- Page 1 ASSEMBLY INTRUCTIONS FOR MAXI 16J3 TOP of UNIT When attaching unit to wall put safety bracket in middle of unit with 16 Pan head screw then 25mm Pan head screw into wall. For plasterboard without a stud it is recommend- ed to use a plug with screw (not provided).
- Page 2 MAXI 16J3 RETREIVE FROM PART 2 OF 2 INFILL STEP RETREIVE FROM PART 2 OF 2 YOU WILL NEED TO RETRIEVE THE INFILL AND 3 X 30mm SCREW FROM PART 2, USING YOUR SCREWS PROVIDED, ATTACH THE INFILL TO THE UNDER-SIDE OF THE FRONT MIDDLE FIXED SHELF.
- Page 3 PROCEED TO UN-FOLD YOUR BACK BOARD AND PROCEED TO NAIL IT INTO POSITION MAKING SURE YOU ARE SQUARE AND ON THE EDGE AT ALL TIMES. STAND YOUR UNIT UP AND PROCEED TO INSERT YOUR ADJUSTABLE SHELVING. PUSH THE 4 SHELF PINS (3) INTO THE HOLES PROVIDED ON EITHER SIDE FOR YOUR SHELF TO SIT ON, THE BEST WAY TO DO THIS IS TO COUNT YOUR HOLES UP FROM THE FIXED SHELF SO YOUR SHELVES WILL BE LEVEL.
