TECHTOP TD350 Product Manual page 105

TD350 Series VFD
Set
value
70 Electronic gear selection
71 Switch to the master
72 Switch to the slave
73 Fire mode trigger
74 S1 Triggers output
75 S2 Triggers output
76 S3 Triggers output
77 S4 Triggers output
78–79 Reserved variables
Related parameter list:
Function
code
P05.00
P05.01 Function of S1 terminal
P05.02 Function of S2 terminal
P05.03 Function of S3 terminal
P05.04 Function of S4 terminal
P05.05 Function of HDIA terminal
P05.06 Function of HDIB terminal
P05.07
Function
Name
HDI input type
Reserved variables
When the terminal is valid, the proportional numerator is
switched to the P21.30 numerator of the 2
ratio.
In stopped state, if the function is valid, the master is
used.
In stopped state, if the function is valid, the slave is used.
Enable fire mode function. For relate parameters, please
see fire mode function parameters (P28.25~P28.27).
Please see P06.01-P06.05 and EET (External Event)
LCD notification.
Please see P06.01~P06.05 and EET (External Event)
LCD notification.
Please see P06.01~P06.05 and EET (External Event)
LCD notification.
Please see P06.01~P06.05 and EET (External Event)
LCD notification.
/
Detailed parameter description
0x00–0x11
Ones: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0: No function
1: Forward running
2: Reverse running
3: 3-wire control/Sin
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Running pause
9: External fault input
10: Frequency increase (UP)
-100-
Basic operation instructions
Description
nd
command
Default
value
0x00
1
4
7
0
0
0
0
