TD350 Series VFD

2.1 What this chapter contains

This chapter introduces the basic principles required during installation commissioning. Users can
realize quick installation commissioning by following these principles.

2.2 Unpacking inspection

Check as follows after receiving products.
1. Check whether the packing box is damaged or dampened. If yes, contact local dealers or
TECHTOP offices.
2. Check the model identifier on the exterior surface of the packing box is consistent with the
purchased model. If no, contact local dealers or TECHTOP offices.
3. Check whether the interior surface of packing box is improper, for example, in wet
condition, or whether the enclosure of the VFD is damaged or cracked. If yes, contact local
dealers or TECHTOP offices.
4. Check whether the nameplate of the VFD is consistent with the model identifier on the
exterior surface of the packing box. If not, contact local dealers or TECHTOP offices.
5. Check whether the accessories (including user's manual, control keypad and extension
card units) inside the packing box are complete. If not, contact local dealers or TECHTOP
offices.

2.3 Application confirmation

Check the following items before operating on the VFD.
1. Verify the load mechanical type to be driven by the VFD, and check whether overload
occurred to the VFD during actual application, or whether the VFD power class needs to be
enlarged.
2. Check whether the actual running current of load motor is less than rated VFD current.
3. Check whether the control precision required by actual load is the same with the control
precision provided by the VFD.
4. Check whether the grid voltage is consistent with rated VFD voltage.
5. Check whether the functions required need an optional extension card to be realized.

2.4 Environment confirmation

Check the following items before use.
1. Check whether the ambient temperature of the VFD during actual application exceeds
40° C, if yes, derate 1% for every additional 1° C (for details, see Section B.2.2 "Derating").
In addition, do not use the VFD when the ambient temperature exceeds 50° C.
Note: For cabinet-type VFD, its ambient temperature is the air temperature inside the
cabinet.
