- Page 1 PROJECTION SCREEN INSTALLATION GUIDE KAUBER Frame screen...
- Page 2 The FRAME CLR series are projection screens with a perfectly stretched projection surface, stretched on a stylish aluminium structure. This series is dedicated to UST projectors. IMPORTANT!!! INSTALLATION AND OPERATION NOTES 1.The screen should be installed in a place away from moisture and strong sunlight.
-
Page 3: Screen Mounting
2. Slide the second frame to make a right angle, then use the included “B” bolts to attach the angle to the screen frame (Fig. 3). Adjust the screen profiles to obtain a right angle and tighten the “B” bolts (Fig. 4). Fig.3 Fig. 4 www.kauber.eu... - Page 4 Fig. 7 5. Gently place the folded frame on the projection surface, so that the corners of the frame and the surface look the same on each of the corners (Fig. 8). Fig.8 www.kauber.eu...
- Page 5 7. Start fixing the surface from the corners of the frame by fastening the springs opposite to each other (left – right side of the screen) Fig. 10, Fig. 11, making sure that the surface is evenly stretched. Fig.10 Fig.11 www.kauber.eu...
- Page 6 Make sure the surface is evenly stretched. NOTE! The springs should be fastened by two people, so as to simultaneously fasten the springs opposite to each other. After installing a few springs, the frame can be slightly lifted to relieve surface tension. Fig. 13 www.kauber.eu...
- Page 7 9., proceeding as shown in Fig. 15 to Fig. 18. NOTE! After placing the profiles Fig. 17, slightly lift the screen, so as to reduce the distance between the bolt and the screen profile. Fig. 15 Fig. 16 Fig. 17 Fig. 18 www.kauber.eu...
- Page 8 12. Fix the wall brackets to the frame, using the washers in Fig 19. Remember that it is possible to mount the brackets inside the screen, then the mounting system will not be invisible Fig 20. Fig. 19 Fig. 20 www.kauber.eu...
- Page 9 Advice! Pull off the suspended screen frame at the bottom and attach the metal plate (Fig. 23) to the magnet (Fig. 21). Move the screen as close to the wall as possible. Then, mark the shape of the plate on the wall, which will serve as a template for fixing it (Fig. 24). Fig. 24 Fig. 23 www.kauber.eu...
-
Page 10: Technical Data
C = A + 10 mm B + 10mm C- A + 10 mm D- B + 10 mm Screen depth after assembly 48 mm Thank you for choosing the KAUBER screen We invite you to buy other KAUBER products www.kauber.eu...
