- Page 1 PROJECTION SCREEN INSTALLATION GUIDE WHITE LABEL...
- Page 3 White Label is a series of electric projection screens in aluminum casings. This series has been designed for offices, as well as conference and lecture halls. A very small, elegant housing will fit into any office and conference space. IMPORTANT!!! INSTALLATION AND OPERATION NOTES 1.
-
Page 4: Screen Installation
SCREEN INSTALLATION 1. Using the screws (c), attach mounting brackets to the sides of the screen (a) depending on the mounting method (b) in the wall position (fig. 1a) or ceiling one (fig.1b) Wall mounting Fig.1a Ceiling mounting Fig.1b... - Page 5 2. Depending on the method of mounting, screw the mounting brackets using the mounting dowels to the wall (Fig.2a) or to the ceiling (Fig.2b). NOTE! The mounting dowels provided in the set can be used only for ceilings and walls made of solid materials (for ex.
- Page 6 3. The delivered screen has end positions set in accordance with the order. If the surface of the screen scrolls too low or not enough, correct the bottom end position using the included wrench (fig.3). Before adjustment, check in the warranty card which type of engine your screen is equipped with. NOTE! Adjustments to the end positions can only be made by a qualified person.
- Page 7 Adjusting the end positions (engine type "A" and "A-RTS" - check the engine type in warranty card)) - Correcting the top end position (white end stop). Fig.4 Fig.5 - Correcting the bottom end position (red end stop). Fig.6 Fig.7...
-
Page 8: Electrical Connection
ELECTRICAL CONNECTION NOTE! The screen may only be connected to the power supply by a person with appropriate electrical qualifications. Before installing the screen cassette, lead the power supply cable to the place of installation and then connect it to the screen during installation according to the diagram A (Fig.8A) or according to the diagram B in the case of a screen with built-in radio control (Fig.8B). - Page 9 Connecting a key switch from the set. (The switch is available in the set for screen without a built-in radio control) Fig.9...
- Page 10 Diagram of connecting a key switch to the screen (screens with an "A" type engine) Contact Description Color Brown Phase (L) Blue Zero (N) Yellow-green Earthing Black Brown Fig.10 -10-...
-
Page 11: Technical Data
A- surface width B- surface height F = A+64mm J=A+30mm K=25mm H=95mm G=A+110mm M=A+90mm N=35mm WHITE LABEL + BLACK FRAME A- width of active surface B - height of active surface C = A +100mm D=B+100mm F=A+164mm J=A+130mm K=25mm H=95mm... - Page 12 M=A+190mm N=35mm Technical specifications: Power supply: 230V 50Hz 120W – screen without a built-in radio control Power: 120W – screen with built-in radio control Thank you for choosing the KAUBER screen. We invite you to purchase other KAUBER products -12-...
