4. Battery and Charger
4.1 Charger Requirements
The charger should only be used for charging the batteries. Do not
use your wheelchair while it is charging.
Charger Technical Data
Input voltage:
Output voltage:
Ingress protection level: IPX1
Meets requirement:
4.2 Charger Use and Care
IMPORTANT:
- A full charge requires between 8 to 10 hours, do not overcharge
more than 24 hours.
- To prevent shortening your battery's life, charge the battery at least
once per month when the wheelchair is not being used.
- Do not stop charging until the charging process is finished.
- Repeat use of less than fully charged batteries will shorten the life
cycle of your battery.
- When battery is fully charged, the power indicator will turn green. Do
not stop charging before fully charged this indicator is lit.
- After charging is complete, ensure to turn off the power supply other-
wise the battery will discharge slowly.
- Do not charge more than 24 hours. Over-charging is dangerous.
Follow These Rules to Avoid Issues with Chargers
- If the electric wheelchair doesn't include a charger, please use na-
tional standard charger with output voltage of 24V/DC 1.5A~5A.
- The charger should be well ventilated at all times during charging.
- Do not expose the wheelchair to direct sunlight and humid environ-
ment.
- While charging, the temperature range should be between 50 to 122
°F (10 to 50 °C). If charged at temperatures outside of this range, the
battery can be damaged.
- Never use or sit on the electric wheelchair when charging.
AC220V (110V) ±10%
24V/DC Output current: 1.5~5A
GB 4706.1-2005 and GB 4706.18-2005
14
