Crestron UC-CX100-Z-WM Quick Start Manual

UC-CX100-Z-WM
Crestron Flex Advanced Video Conference System Integrator Kit with a Wall Mounted Control Interface
for Zoom Rooms™ Software
The UC-CX100-Z-WM Crestron Flex advanced integrator kit provides
customizable video conference solution for use with Zoom Rooms™
software. It supports video displays and features a UC presentation
transmitter, a wall mount touch screen and a UC bracket assembly.
The latest firmware must be loaded onto the touch screen prior to
operation. Refer to the touch screen's
download the latest device firmware. The latest UC-CX100-Z-WM
firmware is installed using the auto update feature.
Minimum Requirements:
A certified USB Camera (not included)
l
A certified, AEC-enabled USB speakerphone or DSP device (not
l
included)
A video display (not included) connected to the UC Engine. A second
l
display is optional.
A Zoom Rooms account or activation code (not included)
l
In the Box
Wall Mount Touch Screen
1 10.1 in. Wall Mount Touch Screen (6510814)
Mounting hardware
UC Presentation Transmitter
1 Presentation transmitter (6510936)
1 Power pack (2056363) with cord (2001134)
1 Bracket, power supply (2056257)
product page (resources tab) to
1 Cable, USB to USB, 6.56 ft (2 m) (2056116)
1 Cable, HDMI®, 6.56 ft (2 m) (2056117)
1 Cable, USB 2.0, A to Micro B, 6.56 ft (2 m) (2055504)
8 Screw, 10-9 x 5/8 in. (15.9 mm), Pan Head, Phillips, Black
(2054365)
UC Bracket Assembly
2 Anchor, Drywall, Plastic, 3/8 in. x 1/2 in. (9.5 mm x
12.7 mm) (2052565)
1 Key, Anchor (4529654)
1 Power pack (2045870)
2 Screw, 8-AB x 1-1/2 in. (38.1 mm), Pan Head, Combo
(2052567)
4 Tie Wrap (2047935)
Additional Items
1 Cable, CAT6a, RJ-45 - RJ-45, 20 ft (6.1 m) (6507640)
3 Cable, CAT5e, RJ-45 - RJ-45, 7 ft (2.1 m) (6509924)
1 Cable, DisplayPort™ to HDMI, 6 ft (1.8 m) (6508282)
1 Cable, HDMI, 6 ft (1.8 m) (6503565)
Quick Start
1
