HCC/HCD710AJS, HCC1010AJS, HCC1410AJS, HCC1010WJS, HCC1410WJS,
HMC1010AJS, HMC1410AJS, HMC1010WJS, HMC1410WJS,
HCE1010AJS, HCE1410AJS, HCE1010WJS, HCE1410WJS
HME1010AJS, HME1410AJS, HME1010WJS, HME1410WJS
(See model number configurator on page 2 for details.)
Order parts online
www.follettice.com
Horizon Elite
Ice Machine Models with RIDE
™
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
Installation Instructions for Drop-In
Technology
™
self-contained
01113281R05
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Follett Horizon Elite Chewblet HCC710AJS
Summary of Contents for Follett Horizon Elite Chewblet HCC710AJS
- Page 1 Horizon Elite Ice Machine Models with RIDE Technology ™ ™ Installation Instructions for Drop-In HCC/HCD710AJS, HCC1010AJS, HCC1410AJS, HCC1010WJS, HCC1410WJS, HMC1010AJS, HMC1410AJS, HMC1010WJS, HMC1410WJS, HCE1010AJS, HCE1410AJS, HCE1010WJS, HCE1410WJS HME1010AJS, HME1410AJS, HME1010WJS, HME1410WJS (See model number configurator on page 2 for details.) Order parts online www.follettice.com self-contained...
- Page 2 Chewblet Ice Machine Model Number Configurations ® 1810 Application Configuration Icemaker Voltage Series Condenser MC Maestro™ C 208-230/60/1 (icemaking head) 425 up to A Air-cooled, self-contained V Vision™ S RIDE™ Self-contained only. 425 lbs Chewblet ® W Water-cooled, self-contained H Harmony™ (RIDE remote D 115/60/1 (icemaking head) (193 kg)
- Page 3 Read and complete the following 8 installation steps Unpack Site preparation Dispenser preparation Docking assembly Ice transport tube External connection Internal connection Front cover DROP-IN • RIDE Technology self-contained...
-
Page 4: Unpack Ice Machine
Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack ice machine ➋ ➌ ➊ ➎ ➍ 7/16" DO NOT TILT ICE MACHINE TO ACCESS BOLTS! COMPRESSOR DAMAGE 7/16" WILL RESULT ➐ ➏ DROP-IN • RIDE Technology... -
Page 5: Prepare The Installation Site
• 10-70 psi (69-483 kpa) • 45 to 90 F (7 to 32 C) • Follett recommends the use of an in-line water filtration system (item# 00130286) • This equipment is to be installed with adequate backflow protection to comply with applicable... -
Page 6: Dispenser Preparation
Dispenser preparation Prepare the dispenser. Dispenser preparation Hot Water 160 F (71 C) 12" (304,8mm) min. 4" (101,6mm) • Determine best route for ice transport tube run. Note: 12" (304,8 mm) clearance is required. • Drill 1 3/4" (44,5 mm) hole through either side of dispenser ➊... -
Page 7: Before Proceeding
Docking assembly Install the docking assembly. BEFORE PROCEEDING Prior to installing the docking assembly, ensure that the drain fitting is oriented (right or left) correctly for your installation. An optional straight drain fitting is also supplied. You may need to remove the back panel of the docking assembly in order to re-orient or change the drain fitting. - Page 8 Undercounter installation detail Front View Top View Access panel/ door on counter ➌ ➊ 2" (51 mm) ➍ 1010/1410: 2.25" (57 mm) 710: 2" (51 mm) bottom of ice machine side of ice machine 1010/1410: 2" (51 mm) 710: 3.25" (82.55 mm) CAUTION •...
-
Page 9: Ice Transport Tube
Ice transport tube Install the ice transport tube. Ice transport tube installation. ➋ Hot Water 160 F (71 C) ➎ ➊ 1/4" ➌ ➍ ➏ ➐ Ice transport tube tips • Insulate entire length of ice transport tube ➊ • Secure ice transport tube ➋... -
Page 10: External Connections
External connections Connect utilities to docking assembly. Air-cooled ice machines only Water-cooled ice machines only ➊ ➊ ➋ ➏ ➋ ➐ ➌ ➌ Minimum 8" ➏ Minimum 8" ➑ radius radius 2 ft. x 1" OD 2 ft. x 1" OD silicone tubing silicone tubing 3/4"... - Page 11 Chassis drain plumbing - required • Plug must be removed from John Guest fitting. • Route 3/8" drain tubing through knockout in back of docking station and insert fully into John Guest fitting connection at the rear of the machine chassis. Route other end of 3/8"...
-
Page 12: Internal Connections
Internal connections Connect docking assembly to ice machine. CAUTION • Plug must be accessible after final installation. • H_E1410A/W 230/50/1) requires a 20 amp circuit (4.00 mm wire) Air-cooled ice machines – follow steps 7.1 through 7.5. Water solenoid, shut-off valve, Ice transport tube and potable water line options If water solenoid is already mounted to... - Page 13 Water-cooled ice machines – follow steps 7.6 through 7.12. TDS switch Cooling lines HIGH CLEAN • Set the TDS switch on the electrical box: • Install ice machine cooling water lines to docking assembly HIGH: for extended service life LOW: for low-scale water Ice transport tube Water solenoid, shut-off valve, and potable water line options...
- Page 14 7.10 Cooling lines and power Power cord ➋ ➊ • Remove twist tie • Carefully pass cord thru opening and plug • Connect cooling water lines to ice into wall outlet machine (Water "Out" connects to water • For H_E units, install a suitable plug regulator.) ➊...
-
Page 15: Front Cover
Front cover Install front cover to ice machine. Front cover installation – Install front cover air-cooled undercounter only ➊ ➋ ➋ ➌ ➊ ➌ • Slide ice machine cover over machine ensuring that tabs on back of cover slip under louvers on back of docking assembly ➊... - Page 16 • Secure insulated ice transport tube at least every 2 ft (0,6m) to prevent dips or traps ➋ Maestro, Micro Chewblet, Vision, Harmony, Ice Manager, Horizon, Horizon Elite are trademarks of Follett Products LLC. Chewblet, RIDE, Follett are registered trademarks of Follett Products LLC.
