- Page 6 1) Insert dowels (#I) to the holes of front left leg (#1) and left rear leg (#2), then align and attach footboard frames (#5,6) to the dowels (#I) of the legs (#1,2). 2) Secure footboard frames (#5,6) to legs (#1,2) with bolts (#C). 1) Insert dowels (#I) to the holes of front right leg (#3) and right rear leg (#4), then align and attach footboard frames (#5,6) to the dowels (#I) of the legs (#3,4).
- Page 7 1) Insert 2 dowels (#I) to each side of the back and front guardrails (#11,12). Insert 2 barrel nuts (#B) to each side of the lower side rails (#7,8) and upper side rails (#9,10). Align back and front guardrails (#11,12) to the upper holes of the headboard/ footboard posts.
- Page 8 Align the guardrail supports (#13) to the upper guardrails, then secure with screws (#H). Align the ladder rung (#17) to the ladder rails (#15,16). Secure with screws (#G).
- Page 9 Align the ladder to the holes of the guardrails. Secure with bolts (#E). Align slat kits (#18) to the upper and bottom side rails. Secure with screws (#H).
