Attach the rotation axis (Q) to the backrest tube (N) with a hex bolt (W2).
4
Attach the base tubes (F) to the stand tubes (E) with two hex bolts (W3), four washers (S5)
and two nylon nuts (S6). Screw the stand tubes (E) and the rotation axis (Q) together with
two hex bolts (S4) and two washers (S5).
W2
E
S5
S4
W3
F
S5
S6
N
Q
