EasyStand Bantam Owner's Manual

Hide thumbs Also See for Bantam:
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual

Advertisement

Table of Contents
loading

Related Manuals for EasyStand Bantam

Summary of Contents for EasyStand Bantam

  • Page 1 Owner’s Manual...
  • Page 2 Vis venligst hensyn til miljøet ved at levere produktet til det nærmeste genbrugsanlæg, når det ikke længere fungerer. Por favor, assuma responsabilidade ambiental, reciclando este produto em suas instalações de reciclagem no final de sua vida útil. 800-342-8968 www.easystand.com...

  • Page 3: Table Of Contents

    Table of Contents Introduction ........1 Safety Precautions ......2 Assembly .

  • Page 4: Introduction

    To help you stay compliant with your standing program, we have created "Standing Room Only", a space on our website dedicated to EasyStand Users. The goal of Standing Room Only is to help you keep your standing program and health "top of mind".

  • Page 5: Safety Precautions

    Medical Inc. does not recommend that you use the EasyStand Bantam. Bantam (Extra Small) - is designed to accommodate most individuals from 28"-40" (71-102 cm) and up to 50 lbs. (23 kg). Bantam (Small) - is designed to accommodate most individuals from 36"-54" (91-137 cm) and up to 100 lbs. (45 kg).

  • Page 6: Assembly

    Assembly The basic stander consists of three assemblies. Options will be in addition to these three assemblies. • Front Frame • Seat Post / Rear Frame • Kneepads Remove the two bolts from front frame. Flip up the rear frame to allow easier access to the post.
  • Page 7 Place the two curved nuts into the bottom of the frame so they are flush with the tube. Place the two bolts into the top of the frame and screw into the curved nut. Tighten securely. Flip the unit back down to the normal position.
  • Page 8 If you ordered the Supine option, remove the locking handle and set hardware aside, you will need this later in the assembly process. Small Extra Small Line up the following arm with the back angle tube. Depress the spring button to allow the following arm to slide into place.
  • Page 9 If you did not order the supine option, skip to step 12. Hardware is shown in order as it should be assembled on the unit: 1. Bolt 2. Nylon Washer 3. Beveled Metal Washer 4. Small Metal Washer 5. Supine Locking Handle Follow the steps for placing hardware on unit: Nylon A- Insert nylon washer in between the brackets...
  • Page 10 Repeat steps for the opposite side. Metal Washer For information on kneepad adjustments see pg. 10. Your standard EasyStand Bantam is now fully assembled. If you ordered the optional Shadow Tray, loosen the ratchet handles on the side of the tray, flip the arms up and tighten the ratchet handles.

  • Page 11: Supine Option Usage

    Supine Option The Supine Option can be added to the EasyStand Bantam. A head support is required when using the Bantam in the supine position. Flat to Load Transfers: Children who are difficult to transfer due to high tone can utilize the Bantam with the supine option to do a flat-to-load transfer or a knee/hip flexion (with a slight bend at the knees and hips) transfer.
  • Page 12 Supine Usage 1. To utilize the 2. Position back and supine option, flip footplate to desired the lever down to angle. the supine position. Ensure the lever is fully retracted to the unlocked mode when using the supine option, failure to do so may cause damage to your unit.

  • Page 13: Adjustments & Usage

    Adjustments & Usage FIG. A Footplates Height Caution: Never reposition the foot holders with the user in the standing position. FIG. B Caution: Avoid placing fingers in the adjustment slot. Plantar/Dorsi FIG. A-Height-The standard footplates have height adjustment. Loosen the clamp connecting the foot bracket to the seat post to adjust footplate height.
  • Page 14 The Bantam Extra Small back angle adjustments are located above the locking knob. The back angle adjustments go from green (largest) to blue (smallest). The Bantam Small back angle adjustments are located under the locking knob. The back angle adjustments go from blue (smallest) to green (largest).
  • Page 15 Hip Supports/Lateral Supports Options FIG. O FIG. O- The hip supports are optional and can be removed for transferring. The hip support width can be adjusted by loosening the knobs underneath the seat. Loosen the knob on the side of the unit to adjust the hip support width. Always tighten securely.

  • Page 16: Pow'r Up Lift Option

    Pow’r Up Lift Option Charging the Battery FIG. A The EasyStand Bantam Pow'r Up Lift uses two 12 volt sealed lead batteries rated at 2.9 amps each. An EasyStand Bantam can be lifted approximately 100 times on one full battery charge. An audible alarm will sound when the battery is low.
  • Page 17 FIG. E FIG. E- Place black plastic button onto the end of the hand control knob. CAUTION: The Bantam Pow’r Up Option is not de- signed for continuous use. Duty Cycle 5% Max, 1 min. / 19 min. page 14...
  • Page 18 Battery Replacement Note: If your control box (which includes the batteries) is within the 90 day warranty, please do not open the control box, contact Altimate Medical customer service for a replacement. Once your batteries have reached the end of their life and need to be replaced, please follow the instructions below.
  • Page 19 Activating the Mechanical Emergency Release CAUTION: Using the emergency mechanical re- lease as the primary means to return to the seated position can cause damage to your unit. Only use the mechanical release in emergency situations. All Altimate Medical electric lift products are equipped with a mechanical release to be used in emergency situations.

  • Page 20: Parts Detail

    EasyStand ® Bantam Parts Detail page 17 Parts Detail...

  • Page 21: Maintenance

    The very close fit of its mating parts gives each pump its own break-in “feel” and signature sound. • If the pump is leaking oil, call your local EasyStand Supplier for a replacement. The serial number on your EasyStand will be needed.

  • Page 22: Specifications

    Specifications Height Range (extra small) 28”-40” 71-102cm (small) 36”-54” 91-137cm Weight Limit (extra small) 50 lbs 23kg (small) 100 lbs 45kg Seat Depth Range (extra small) 6"-11" 15-28cm (small) 10"-15" 25-38cm Seat Height from Floor (transfer height) 19" 48cm Seat to Foot Plate Range 10"-16.5"...

  • Page 23: Limited Warranty

    Limited Warranty This warranty is extended only to the original purchaser/customer (or supplier non consumer who does not buy or resell). Altimate Medical, Inc. (AMI) warrants the EasyStand Bantam against defects in materials and workmanship as listed below. • Steel Frames - 5 year warranty •...
  • Page 24 Morton, MN 56270 Toll Free: 800.342.8968 or 507.697.6393 Fax Free: 877.342.8968 or 507.697.6900 email: info@easystand.com www.easystand.com Standing technology should only be used under the guidance of a physician with recommendations for standing program protocol and any medical precautions. Standing programs should be monitored by the attending therapist. AMI maintains a policy of continual product improvement and reserves the right to change features, specifications, and prices without prior notification.
