EasyStand Evolv Perfect Fit Manual

Evolv Perfect Fit Guide
Step One - Measure
Before transferring into the Evolv, measure
for approximate (A) seat depth and seat to
(B) foot plate settings.
!
Caution: These adjustments are only to be
made while the unit is unoccupied.
Step Two - Seat Depth
Use the above measurement (A) to adjust
the seat depth on the stander, measure
from the front of the seat to the back. To
adjust the seat depth, loosen the knob
under the seat (C). Depress the snap
button on the adjustment tube while
moving the back (D). Adjust the seat depth
until the proper measurement has been
reached. Tighten the knob (C) after
adjusting.
!
Caution: The following adjustments are only
to be made in the seated position.
Step Three - Back Angle
After achieving the desired seat depth,
rotate the back angle (E) adjustment knob
so the (F) seat/back angle indicator is in
the green area prior to standing.
Note: Repeat steps 2 and 3 for each color
adjustment.
Step Four - Foot Plates
Use the (B) measurement to adjust the
foot plate height. Loosen the (G) ratchet
handles on the foot plates to adjust height
and plantar/dorsi. Tighten ratchet handles
after positioning. The knees should be
slightly lower than the hip (H).
Step Five - Positioning
Position the user's hips as close as
possible to (I) Evolv's hip pivot. To
determine correct positioning, only two
fingers should fit between the front of the
seat and the back of the knee (J).
Step Six - Knee Pad
Adjust the (K) knee pad so it fits
comfortably up to the knees.
Inspect your standing frame periodically to
ensure it is in safe operating condition.
s t nd.com
®
(A)
(C)
(E)
(G)
(I)
(K)
(B)
(D)
(F)
(H)
(J)
