EasyStand Bantam Fit Manual

Step One - Foot Plates
Before the child is in the stander, loosen
the clamps (do not remove) on the
foot plates to adjust height (A). The knees
should be slightly lower than the hips (B).
Tighten clamps securely.
Step Two - Seat Depth/Back Angle
Make adjustments before the child is in
the stander. For easier adjustment,
remove the Shadow Tray and raise seat
to a slight angle. If you have the Supine
Option, make sure the red supine locking
handles are loose.
Loosen the knobs on the seat tube and
the following arm (but do not unscrew
completely).
Adjust to a shorter seat depth
setting, first, adjust the following arm
(back angle) by depressing the spring
button and moving no more than two
holes at a time. Then adjust the seat
tube (seat depth) one hole at a time.
Continue this sequence until you achieve
the desired setting, and the colors on the
seat tube and following arm match (C).
Adjust to a longer seat depth
setting, first, adjust the seat tube (seat
depth) by depressing the spring
button and moving only one hole at a
time. Then adjust the following arm (back
angle) no more than two holes at a time.
Continue this sequence until you achieve
the desired setting, and the colors on the
seat tube and following arm match (C).
For easier adjustment, use the seat
bracket or the lift assist handle to lift
slightly as the seat depth adjustment is
made (D).
Step Three - Knee Pads
Position the user's hips as close as possible
to stander's hip pivot (E). To determine
correct positioning, fit two fingers between
the front of the seat and the back of the
knee (F). Adjust and secure the knee pads
so the knees are centered in the pads.
www.e syst nd.com
Bantam Perfect Fit Guide
™
Tip:
• Position foot plate height so the femur is resting on the seat.
Tips:
• Remove Shadow Tray and bring seat up to a slight angle.
• Start with the smaller tube to adjust to a shorter setting.
• Start with the bigger tube to adjust to a longer setting.
Tips:
• Position child's hips in seat to match stander's hip pivot.
• You should be able to fit only 1-2 fingers behind the knee.
For more detailed information refer to your owner's manual.
A
C
Seat
Tube
Following
E
B
D
Arm
F
800•342•8968
